Артикул
Название
Примечание
Количество
1
87588897
MOTOR-PUMP,50.9 CC
2-Spd Motor, Track Drive
2шт.
1
87588897R
REMAN-HYD MOTOR
2шт.
1
87588897C
CORE-MOTOR HYDRAULIC
Return Number
2шт.
2
84277065
ADAPTER,3/4" - 16 ORB x -8 Fem Quick Lock
8FQLL-8MB
2шт.
3
84277064
ADAPTER,9/16" - 18 ORB x -6 Fem Quick Lock
6FQLL-6MB
4шт.
4
84331670
GROMMET
Chassis, Years: -05-JAN-16
2шт.
4
47893401
GROMMET
Chassis, Start Year: 06-JAN-16
2шт.
5
84280449
RIGID TUBE
Assy, Brake RH
1шт.
6
84280444
RIGID TUBE
Assy, Case Drain RH, Must Order Ref. 9 Adapter
1шт.
7
84331874
PLATE
Grommet, Gray
2шт.
8
84280452
FLEXIBLE HOSE,9.53mm ID x 1245mm L, SAE 100R1
Assy, Two Speed RH, Must Order Ref. 3 Adapter
1шт.
9
84277066
ADAPTER,- 12 Fem Quick Lock HP x 1-1/16" - 12, - A3512 ORB
Female, HP Quick Lok, Years: -05-JAN-16
4шт.
9
87303844
HYD CONNECTOR,1-7/16" - 12 ORFS x 1-1/16" - 12 ORB
, Start Year: 06-JAN-16
4шт.
10
84280448
RIGID TUBE
Assy, Brake LH
1шт.
11
84280451
FLEXIBLE HOSE,9.53mm ID x 1045mm L, SAE 100R1
Assy, Two Speed LH, Must Order Ref. 2 Adapter
1шт.
12
84280443
HYD TUBE
Assy, Case Drain LH, Must Order Ref. 9 Adapter
1шт.
13
84257173
HOSE,12.7mm ID x 570mm L
Brake Drain
1шт.
14
87443510
HOSE CLAMP,18.4mm Static ID x 15mm W
4шт.
15
84187294
ADAPTER,12.7mm OD Hose Bead x 12.7mm Hose Bead x 9/16" - 18 ORB
Fitting
1шт.
16
86511844
BOLT,M8 x 1.25 x 100mm, 22mm Thd, Cl 8.8
Flange, 8.8, M8 x 100
2шт.
17
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
Square, M8-1.25
2шт.
18
84256534
HYDRAULIC VALVE
EH Track Brake Valve, See Ref. 23-29
1шт.
21
86513020
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
1шт.
22
84388282
INDICATOR
High Speed
2шт.
23
84311814
PRESSURE SWITCH
Brake Pressure, Valve (Not Shown)
1шт.
24
84311813
PRESSURE SWITCH
Charge Pressure, Valve (Not Shown)
1шт.
25
84390140
COIL
Interlock (Not Shown)
1шт.
26
84390142
COIL
2 Speed (Not Shown)
1шт.
27
84311809
SEAL KIT
Brake, Interlock, 2 Speed Seal (Not Shown)
3шт.
28
84311808
HYDRAULIC VALVE
Brake, Interlock, 2 Speed 3W2P Spool (Not Shown)
3шт.
29
84390141
COIL
Brake (Not Shown)
1шт.
