Запчасти Case TR340 (50.100.AP[03]) - HVAC SYSTEM (50) - CAB CLIMATE CONTROL

Схема запчастей Case TR340 - (50.100.AP[03]) - HVAC SYSTEM (50) - CAB CLIMATE CONTROL
90.150.bd 02
12
23
17
22
19
13
24
3
1
13
10
7
8
16
3
24
10
6
9
20
14
5
17
2
15
21
18
11
4
55.101.ac 09
50.100.ap 01
50.200.ak
50.200.by
50.200.by
50.100.ac 01

Артикул

Название

Примечание

Количество

1

350459

CARRIAGE BOLT,Rnd Head, M10 x 1.5 x 50mm, Full Thd, Cl 8.8

1шт.

2

9804261

BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd

1шт.

3

9804278

FLANGE NUT,M10 x 1.5, Cl 8

3шт.

4

47568942

DUCT

529.4mm L, Air Intake

1шт.

5

47679222

BRACKET

HVAC Hose Spring Mount

1шт.

6

84272827

RIVET,Flat Flg Head, 12.7mm OD x 17.4mm L

4шт.

7

84347258

DECAL

HVAC

1шт.

8

84361522

BRACKET

Loader Valve, Spring Mount

1шт.

9

84380240

BRACKET

Relay

1шт.

10

86511833

SCREW,Phillips Drive, Pan HD, M6 x 40mm

4шт.

11

86512441

CARRIAGE BOLT,Rnd Head, M6 x 1 x 36.6mm, Cl 8.8

2шт.

12

86619800

FLANGE NUT,M6 x 1, Cl 8

2шт.

13

86624183

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

3шт.

14

86729669

SWITCH

Blower

1шт.

15

86729670

KNOB

Control

2шт.

16

86729675

SWITCH,5000 Ohm

Switch

1шт.

17

87310592

JAM NUT,7/16" - 28, Gr 5

2шт.

18

87355337

RELAY,12V, 45A

Blower

1шт.

19

87555249

SWITCH

31.75mm L, A/C

1шт.

20

87655042

SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk

2шт.

21

87655046

SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk

1шт.

22

412679A2

SPRING,Extension, 22.5mm OD x 173mm L

2шт.

23

414635A1

COVER,25.4mm OD x 0.51mm Thk

2шт.

24

D39696

CLAMP,25.40mm - 13.49mm Bolt, CTD

4шт.

Выбрано товаров: 24
