Запчасти Case TR320 (90.180.01[04]) - DECALS (TR320) (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case TR320 - (90.180.01[04]) - DECALS (TR320) (90) - PLATFORM, CAB, BODYWORK AND DECALS
1
5
home
4
2
3
6

Артикул

Название

Примечание

Количество

1

87673472

DECAL

Grease Spring Warning

2шт.

2

84367429

WARNING DECAL

Crush Hazard

1шт.

3

84367585

DECAL

Lubrication, Radial

1шт.

4

84350667

DECAL

Operating Capacity

1шт.

5

84357636

DECAL,53mm OD, Gray

Plug, Loader Latch Access Hole

1шт.

5

429630A2

CAP COVER,43mm OD

Lexan, 43mm, Loader Arm

1шт.

6

299274A2

COVER,35mm OD

Lexan

4шт.

Выбрано товаров: 7
