Запчасти Case TR310 (90.100.BE[01]) - HD REAR DOOR (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

140020

WASHER,17.5mm ID x 30mm OD x 3mm Thk

8шт.

2

290323

HOSE,5/16" ID x 500 FT L, SAE 30R7

1.92" L

1шт.

3

337476

BOLT,Hex, M12 x 1.75 x 50mm, Cl 10.9

1шт.

4

9804255

BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8

4шт.

5

9804258

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

6шт.

6

9804261

BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd

1шт.

7

9804278

FLANGE NUT,M10 x 1.5, Cl 8

1шт.

8

47590929

ROD

7.94mm OD, Rear Door Latch

1шт.

9

47817318

DOOR

911mm L

1шт.

10

47824048

ANGLE

RH, Door Seal

1шт.

11

47824050

ANGLE

LH, Door Seal

1шт.

12

47827930

SPACER

938.4mm L, Bumper

1шт.

13

84163981

FLANGE BOLT,Hex, M6 x 20.56mm

6шт.

14

84200915

CAPPING

Rear Door

1шт.

15

84201449

DOOR SEAL,580mm L

Upper Bulb

1шт.

16

84201450

DOOR SEAL,575mm L

Side Bulb

2шт.

17

84306545

BUSHING,12.5mm ID x 23.5mm OD x 16mm L

Door Hinge

1шт.

18

84306554

LOCKING PLATE

Door

1шт.

19

84355007

ANGLE

Light Mounting

2шт.

20

84554254

TRIM,30480mm L

1шт.

21

86511444

FLANGE NUT,Hex, M6 x 1

4шт.

22

86619800

FLANGE NUT,M6 x 1, Cl 8

4шт.

23

86625256

WASHER,13.3mm ID x 28.5mm OD x 4mm Thk

1шт.

24

86625260

WASHER,21.8mm ID x 37.5mm OD x 4mm Thk

1шт.

25

87015931

BOLT,Hvy Hex, M6 x 35mm, Cl 8.8

4шт.

26

87352559

SPACER,13.10mm ID x 15.90mm OD x 6.4mm L

15.9mm OD, Door Lock

1шт.

27

87437076

LATCH

Assy

1шт.

28

87578980

RUBBER SEAL,590mm L

1шт.

29

87681209

FLANGE NUT,Hex, M12 x 1.75, Cl 10

1шт.

30

87698850

BOLT,M16 x 100mm, Cl 10.9

4шт.

31

380751A1

NUT

5.2mm Thk, Push Cap

1шт.
