1
9804257
FLANGE BOLT,Hex, M6 x 1.0 x 25mm, Cl 8.8, Full Thd
4шт.
2
9804258
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
1шт.
3
9804277
FLANGE NUT,Hex, M8 x 1.25, Cl 8
1шт.
4
47415611
HOSE ASSY.,12.7mm ID x 1600mm L
Compressor to Condenser, Incl 13, 15 - 18
1шт.
5
47435321
HOSE ASSY.
Condenser to Receiver/Dryer, Incl 12
1шт.
6
47534057
A/C HOSE
Evaporator to Compressor, Incl 14, 19 - 21
1шт.
7
84403037
HOSE ASSY.
Receiver/Dryer to Evaporator, Incl 12
1шт.
8
86625034
HOSE CLAMP,90.4mm - 114.3mm, Worm Gear
2шт.
9
86625073
SPRING NUT,M6 x 1
4шт.
10
86637978
CLAMP,9.5mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
11
87000227
SWITCH, A/C HIGH PRE
1500 Volts Terminal to Case
1шт.
12
128483A1
O-RING,1.78mm Thk x 7.65mm ID, 70 Duro
4шт.
13
128484A1
O-RING,0.07" Thk x 0.426" ID, -13, Cl 5, 70 Duro
High Side Hose
2шт.
14
128485A1
O-RING,1.78mm Thk x 14mm ID, 70 Duro
Low Side Hose
2шт.
15
414080A1
CAP,M10 x 0.75 x 22.35mm L, Black
High Side Service Port
2шт.
16
414078A1
FITTING,M10 x 0.75 x 38.61mm L
High Side Service Port
2шт.
17
1250594C2
CORE
High Side Valve, A/C Pressure Switch Fitting
1шт.
18
122081A1
FITTING,M10 x 1.25 x 26.43mm L
High Side, A/C Pressure Switch
1шт.
19
414081A1
CAP,M8 x 1 x 17.3mm OD x 21.1mm L
Low Side Service Port
2шт.
20
414083A1
VALVE
Low Side Service Port
2шт.
21
414079A1
VALVE
Low Side Fitting
2шт.
22
L11541
CABLE TIE,203.2mm L, Nylon
1шт.
