Запчасти Case TR270 (50.100.AC[02]) - HEATER MEDIUM FRAME (50) - CAB CLIMATE CONTROL

Схема запчастей Case TR270 - (50.100.AC[02]) - HEATER MEDIUM FRAME (50) - CAB CLIMATE CONTROL
11
9
3
16
35.000.00
4
4
10
12
15
14
7
5
6
7
90.150.bd 03
50.100.ac 01
50.100.ap 02
2
13
8
1

Артикул

Название

Примечание

Количество

1

350459

CARRIAGE BOLT,Rnd Head, M10 x 1.5 x 50mm, Full Thd, Cl 8.8

1шт.

2

9804258

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

3шт.

3

9804261

BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd

1шт.

4

9804278

FLANGE NUT,M10 x 1.5, Cl 8

3шт.

5

L11541

CABLE TIE,203.2mm L, Nylon

1шт.

6

47416077

GUARD

Fan

1шт.

7

D39696

CLAMP,25.40mm - 13.49mm Bolt, CTD

2шт.

8

87655046

SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk

1шт.

9

84272827

RIVET,Flat Flg Head, 12.7mm OD x 17.4mm L

4шт.

10

84280313

AIR DUCT

External

1шт.

11

87655042

SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk

2шт.

12

86511833

SCREW,Phillips Drive, Pan HD, M6 x 40mm

4шт.

13

86512441

CARRIAGE BOLT,Rnd Head, M6 x 1 x 36.6mm, Cl 8.8

2шт.

14

86619800

FLANGE NUT,M6 x 1, Cl 8

2шт.

15

86624183

WASHER,6.6mm ID x 25mm OD x 1.6mm Thk

4шт.

16

86625263

WASHER,9mm ID x 20mm OD x 1.6mm Thk

3шт.

Выбрано товаров: 16
