1
140020
WASHER,17.5mm ID x 30mm OD x 3mm Thk
4шт.
2
350616
BOLT,M16 x 2 x 90mm, Cl 8.8
4шт.
3
9804262
BOLT,M10 x 39.2mm, Cl 8.8
1шт.
4
9804264
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
2шт.
5
84273170
COVER PLATE
Battery Compartment
1шт.
6
84274252
BUMPER
Right
1шт.
7
84274254
BUMPER
Left
1шт.
8
84274279
FRAME
Rear
1шт.
9
84355546
FOAM INSULATION,215mm L
Counterweight
1шт.
10
86625071
SPRING NUT,M10 x 1.5
3шт.
11
87655047
SPECIAL WASHER,21.25mm ID x 38.10mm OD x 4.20mm Thk
1шт.
12
87675533
BOLT,M16 x 75.4mm, Cl 10.9
6шт.
