Запчасти Case TR270 (10.202.AD) - AIR FILTER, LINES, ELECTRONIC CONTROLS (10) - ENGINE

1

120038

CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 30mm, Cl 8.8, Full Thd

3шт.

2

87611895

GASKET,0.4mm Thk

Muffler

1шт.

3

9671714

FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

8шт.

4

9804258

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

7шт.

5

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

7шт.

6

86511842

BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8

3шт.

7

47541188

CLAMP,68mm ID, Muffler

68mm ID

1шт.

8

86050202

HOSE CLAMP,1.59” - 2.5”, Worm Gear

1шт.

9

84588569

CLAMP,54mm ID, Muffler

1шт.

10

84287181

EXHAUST SYSTEM PIPE

Exhaust

1шт.

11

84287182

MUFFLER

Bilen, F5C

1шт.

12

84287183

EXHAUST SYSTEM PIPE

Tailpipe

1шт.

13

84309314

BRACKET

Air Cleaner

1шт.

14

84495949

EXTENSION

Exhaust Stack

1шт.

15

84365650

BRACKET

Muffler

2шт.
