Запчасти Case 450CT (06-40) - FINAL DRIVE (450CT) REXROTH DRIVE MOTORS (06) - POWER TRAIN
№
Артикул
Название
Примечание
Количество
1
87669355
FRAME
Track Frame RH, Used with Rexroth Drive Motors
1шт.
2
87016615
WASHER,15.3mm ID x 28.5mm OD x 3mm Thk
24шт.
3
87303344
BOLT,Hex, M14 x 85mm, Cl 10.9
24шт.
4
412087
BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd
4шт.
5
86625255
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
4шт.
6
337475
NUT,M12, Cl 10
4шт.
7
87589343
PLATE
Scraper Plate, Used with Rexroth Drive Motors
2шт.
8
86508624
BOLT,Hex, M16 x 45mm, Cl 10.9
12шт.
9
86639326
WASHER,17.3mm ID x 34.5mm OD x 5mm Thk
28шт.
10
87460888
SPROCKET
17 Tooth,86 Pitch
2шт.
12
87303345
HEX SOC SCREW,M16 x 2 x 40mm, Cl 10.9, Full Thd
16шт.
13
87480413
IDLER,290mm OD x 220mm W
Replaces 87447230; 87535299
2шт.
15
86592703
WASHER,21mm ID x 50mm OD x 6mm Thk
4шт.
17
87480419
TRACK ROLLER
Replaces 87535297; P/n includes Roller Shell, Shaft, Brackets, Plugs, O-rings, Sealing Rings, Bushings- All NSS
8шт.
18
86512498
FLANGE NUT,M16 x 2, Cl 10
16шт.
19
87669353
FRAME
Track Frame LH, Used with Rexroth Drive Motors
1шт.
20
43127
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
4шт.
21
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
4шт.
22
87354210
COVER
2шт.
23
87480418
FRONT IDLER,350mm OD x 194mm W
350 mm, Front; If Used; Replaces 87462176, 87535298
2шт.
23
47378990R
REMAN-WHEEL IDLER
350 mm, Front
2шт.
23
47378990C
CORE-WHEEL IDLER
Return Part Number
2шт.
24
14301821
HEX SOC SCREW,M10 x 16mm, Cl 8.8, Full Thd
4шт.
25
87462287
YOKE
2шт.
26
87602985
TENSIONER
Cylinder, Spring Tensioner; Incl 27, 28, 29
2шт.
27
87602987
SERVICE KIT
Kit For 87602985; Incl Scraper, Spacer, O-Ring
1шт.
28
87602988
ROD
1шт.
29
87356572
VALVE
Grease Valve
1шт.
84213764
CAP
Cap, Grease Valve For Tension Spring 87602985
1шт.
30
87650011
SERVICE KIT
Shim Kit; Incl 31, 32
1шт.
31
87650010
PLATE
Plate, 16 Gage Shim
2шт.
32
87650009
PLATE
Plate, 12 Gage Shim
2шт.
Выбрано товаров: 34
