1
120100
BOLT,M6 x 20mm, Cl 8.8
If Used
2шт.
1
86977726
BOLT,Hex, M6 x 12mm, Cl 8.8
2шт.
2
86517328
LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk
2шт.
3
87643562
BRACKET
Throttle Rod Bracket; No Longer Used, Order Ref 31, 87051143
1шт.
4
88098
JAM NUT,Jam, 1/4"-28, G2
1шт.
5
80682
LOCK WASHER,1/4"
1шт.
6
87756618
THREADED ROD
Throttle Rod; Replaces 87688638; If Used
1шт.
6
87752022
ROD
Throttle Rod
1шт.
7
87028524
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type
2шт.
8
694371
SPACER,9.77mm ID x 15.87mm OD x 5.03mm Thk
2шт.
9
A177436
KNOB
1шт.
10
H169920
BALL JOINT
3шт.
11
87712373
THROTTLE CONTROL
Hand Throttle
1шт.
12
1342374C1
DISC
1шт.
13
R14771
WASHER
1шт.
14
86625256
WASHER,13.3mm ID x 28.5mm OD x 4mm Thk
2шт.
15
87712376
THROTTLE CONTROL
Throttle Control
1шт.
16
86509309
NUT,1/4"-28, G5
2шт.
17
187035A2
SLEEVE
1шт.
18
186905A1
BUSHING
Throttle Bushing
1шт.
19
87424095
SLEEVE
Throttle Pivot
1шт.
20
87416539
TORSION SPRING
1шт.
21
87612749
BOLT,Hex, M12 x 60mm, Cl 10.9
Bolt, M12 X 60 10.9
1шт.
22
86976064
JAM NUT,Jam, 1/4"-28, G5
3шт.
23
87650094
ROD
Throttle Rod, Foot
1шт.
24
D131983
COTTER PIN,1.04mm OD x 21.4mm L, Ring
1шт.
25
86639313
WASHER,9mm ID x 24mm OD x 2mm Thk
1шт.
26
16044321
BOLT,M8 x 1.25 x 55mm, Cl 8.8
1шт.
27
87725977
PEDAL
Foot Pedal; Replaces 87650090
1шт.
28
323657A1
PAD
Foot Pedal Pad
1шт.
29
43117
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8
`
1шт.
30
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
1шт.
31
87051143
ROD ASSY.
If Used
1шт.
31
87752021
BRACKET
Throttle Bracket
1шт.
32
88098
JAM NUT,Jam, 1/4"-28, G2
1шт.
33
80682
LOCK WASHER,1/4"
1шт.
34
120100
BOLT,M6 x 20mm, Cl 8.8
If Used
2шт.
34
86977726
BOLT,Hex, M6 x 12mm, Cl 8.8
2шт.
35
86517328
LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk
1шт.
36
86625036
CLAMP,12.7mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
37
86505868
SERRATED NUT,Hex, M8 x 1.25, Cl 8
1шт.
38
120104
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
1шт.
38
43128
BOLT,M8 x 1.25 x 30mm, Cl 8.8
1шт.
39
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
1шт.
40
87352559
SPACER,13.10mm ID x 15.90mm OD x 6.4mm L
Spacer Door Lock
1шт.
41
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
1шт.
