Артикул
Название
Примечание
Количество
1
87705419
TRIM PANEL
Filler, Rear Window LH
1шт.
2
87712706
FASTENER,16mm L, Nylon
Fastener, Push In; If Used
2шт.
3
87713668
FASTENER
Fastener, Push In
6шт.
4
REF
INSTRUCTION
Headliner, Heat And A/C; See Fig 09-53
1шт.
5
414635A1
COVER,25.4mm OD x 0.51mm Thk
Lexan Cover, 25mm (1 in.) Dia; If Used
3-4шт.
6
87718151
HARNESS
Harness, HVAC; If Used
1шт.
6
87482933
HARNESS
Harness, HVAC
1шт.
7
87703530
COVER
Hose Cover, RH; If Used
1шт.
7
84129087
COVER
Hose Cover, RH, Gray
1шт.
7
84129088
COVER
Hose Cover, LH, Gray
1шт.
8
9804258
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
3-6шт.
9
87016586
SPRING NUT,Multi-Thd, M8 x 1.25
3-6шт.
10
L11541
CABLE TIE,203.2mm L, Nylon
CABLE STRAP
3шт.
11
87717211
HEATER HOSE,15.75" mm ID, 3400.00 mm, SAE 20R3
2шт.
12
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
1-4шт.
14
43127
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
1шт.
15
H434289
MOUNTING CLIP,7/8”, Insulated, 1/2” Bolt
1шт.
18
REF
INSTRUCTION
Rear Window, HVAC; See Fig 09-49
1шт.
19
9804256
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
8-13шт.
20
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
If Used
4-10шт.
21
87705420
TRIM PANEL
Filler, Rear Window RH
1шт.
22
87439844
GUARD
3-4шт.
23
87441006
TUBE,4.6mm ID x 1350mm L
Guard, A/C Hose
1шт.
24
87443511
CLAMP,22mm - 26mm, CTB-24, Style C
6-8шт.
25
86729675
SWITCH,5000 Ohm
1шт.
26
87310592
JAM NUT,7/16" - 28, Gr 5
2шт.
28
86729669
SWITCH
Blower Switch
1шт.
29
87687236
DECAL
Decal, HVAC Control
1шт.
30
87555250
PLUG
A/C Switch Plug; If Used
1шт.
31
87520839
VALVE
1шт.
32
87462631
BRACKET
Water Valve And Dryer Bracket; If Used
1шт.
32
87704187
BRACKET
Water Valve And Dryer Bracket
1шт.
34
642560
FITTING,5/8" Hose x 3/8" NPTF Beaded
2шт.
35
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
2шт.
36
87015284
WASHER,8.8mm ID x 21.5mm OD x 2.5mm Thk
2шт.
37
120103
BOLT,M8 x 1.25 x 16mm, Cl 8.8
2шт.
38
86511444
FLANGE NUT,Hex, M6 x 1
4шт.
39
86977786
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8
4шт.
40
87016585
NUT,Spring, M6 x 1
2шт.
41
86619800
FLANGE NUT,M6 x 1, Cl 8
2шт.
43
86624182
WASHER,6.6mm ID x 18mm OD x 1.6mm Thk
10шт.
Выбрано товаров: 49
