Запчасти Case 440CT (06-30A) - HYDROSTATICS - RESONATOR (EUROPE) (06) - POWER TRAIN

Схема запчастей Case 440CT - (06-30A) - HYDROSTATICS - RESONATOR (EUROPE) (06) - POWER TRAIN
6
4
5
3
1
7
2

Артикул

Название

Примечание

Количество

87719310

SERVICE KIT

Incl 1 - 7 And 08-16, 08-17, 08-18

1шт.

1

9790527

PLUG,1-5/16" - 12 JIC

1шт.

2

87595771

ISOLATOR,200mm L x 50mm W x 3.2mm Thk

Rubber Isolator

1шт.

3

L18331

CABLE TIE,375.9mm L, Nylon, Black

CABLE STRAP

1шт.

4

87717826

HOSE,25.4mm ID x 475mm L

Hose, Resonator

1шт.

5

219605

ELBOW,45 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw

1шт.

6

87399014

ADAPTER

Tee 3/4 X 3/4 X 5/8 37FL; Incl 7

1шт.

7

167266

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

Выбрано товаров: 8
