Артикул
Название
Примечание
Количество
1
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
5шт.
2
87030567
SQUARE NUT
3шт.
3
87042897
SPACER
1шт.
4
87301359
CLAMP,28.6mm, 10.3mm Bolt Hole, P Type
1шт.
5
87445136
HYD TUBE,18.9 mm ID x 29 mm OD x 21, 2 mm L
1шт.
7
144121
UNION,1-1/16" - 12 JIC x 1-1/16" - 12 JIC
1шт.
8
322894
90 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12 ORB
Incl. 9
1шт.
9
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
10
87364616
HYD TUBE,22.92 mm ID x 25.40 mm OD x 868.6, 368 mm L
Case Drain
1шт.
11
87547065
HOSE,19.05mm ID x 609mm L
609 mm, 24.00 in. Length
1шт.
12
87443510
HOSE CLAMP,18.4mm Static ID x 15mm W
6шт.
13
87364625
HOSE
Case Drain, 1000 mm, 39.37 in. Length
1шт.
14
87547064
HOSE,19.05mm ID x 488mm L
Motor To Pump Loop, If Used; Routed As Shown
1шт.
14
87547067
HOSE,19.05mm ID x 930mm L
Motor To Pump Loop, If Used; 930 mm, 36.61 in. Length; Not Routed As Shown
1шт.
15
L11541
CABLE TIE,203.2mm L, Nylon
CABLE STRAP
1шт.
16
87563997
HOSE,15.88 mm ID x 810.00 mm
Pump Drain
1шт.
17
87443511
CLAMP,22mm - 26mm, CTB-24, Style C
2шт.
18
87364622
HOSE
Case Drain, 715 mm, 28.15 in. Length
1шт.
19
87547067
HOSE,19.05mm ID x 930mm L
Motor To Pump Loop, 930 mm, 36.61 in. Length
1шт.
20
87547066
HOSE,19.05mm ID x 370mm L
Motor To Pump Loop, 970 mm, 38.20 in. Length
1шт.
21
87446248
HYD TUBE,19.05 mm OD x 344.1, 215.2 mm L
Valve To Filter
1шт.
22
15694
TEE,1 1/16"-12 37 Degree
1шт.
23
219606
CAP,1-1/16" - 12 JIC
1шт.
24
87445138
HYD TUBE,19.05 mm OD
Valve To Filter
1шт.
25
84570
90 ELBOW,7/8" - 14 JIC x 1-1/16" - 12 ORB
Incl. 26
1шт.
26
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
27
87575684
HYD CONNECTOR
Flareless
2шт.
29
86512554
NUT,M10 x 1.5, Cl 10
3шт.
31
87563968
HYD TUBE,6.35 mm OD
1шт.
Ref 27 is NOT Included
1шт.
32
87563969
HYD TUBE,6.35 mm OD
1шт.
Ref 27 is NOT Included
1шт.
33
87678506
BRACKET
Hose Support; Replaces 87564009
1шт.
34
9827902
CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
36
9628098
NUT,M8 x 1.25, Cl 10
1шт.
37
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
38
608089
CLAMP
1шт.
39
87030561
NUT,M6 x 1, Cl 8
1шт.
40
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
7шт.
41
120101
BOLT,Hex, M6 x 1 x 30mm, Cl 8.8
1шт.
Выбрано товаров: 44
