Запчасти Case 420CT (06-05A) - HYDROSTATICS - BRAKE VALVE (420CT) (06) - POWER TRAIN

1

REF

INSTRUCTION

See Figure 06-08A

1шт.

2

L18331

CABLE TIE,375.9mm L, Nylon, Black

CABLE STRAP

2шт.

3

87021047

BRAKE VALVE

Brake Valve; Incl. 3A - 3C

1шт.

3a

87424182

BRAKE VALVE

Not Illustrated

1шт.

3b

87433496

COIL

Not Illustrated

1шт.

3c

87458061

PRESSURE SWITCH

Brake Valve; Not Illustrated; Incl. O-Ring Which Is Not Serviced Separately

1шт.

4

217-374

FITTING,90 Degree Elbow, 1/2" Hose Barb x 9/16" - 8 Male ORB

3/8 Hose; Incl. 5

1шт.

5

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

6

43130

BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8

2шт.

7

140016

WASHER,M8 x 16mm OD x 1.6mm Thk

2шт.

8

229197A1

SQUARE NUT,M8 x 1.25, Cl 8

Square, M8-1.25

5шт.

9

76344

90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB

Incl. 10

2шт.

10

9617873

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

11

87369080

HOSE

Hose; Brake, Left Hand

1шт.

12

87015463

HOSE,12.7mm ID x 402mm L

Brake Valve

1шт.

13

87443510

HOSE CLAMP,18.4mm Static ID x 15mm W

6шт.

14

87369083

HOSE

Hose; Case Drain

1шт.

15

87369082

HOSE

Hose; Case Drain

1шт.

16

87369081

HOSE

Hose; Brake, Right Hand

1шт.
