Запчасти Case 75P (114) - NO DESCRIPTION PROVIDED (07) - HYDRAULIC SYSTEM

P1343351

SHIN

BRACKET

1шт.

P32937

SCREW

M10 x 50

6шт.

P1223352

LARGE PLATE

PLATE, LARGE

1шт.

P30403

O-RING,0.103" Thk x 1.049" ID, -121, Cl 6, 90 Duro

2.62 x 26.64-80

4шт.

P38192

COMPRESSION SPRING

2шт.

P1038171

COMPRESSION SPRING

2шт.

P30403

O-RING,0.103" Thk x 1.049" ID, -121, Cl 6, 90 Duro

2.62 x 26.64-80

2шт.

P233094

SCREW

M6 x 6

2шт.

P34564

NUT

2шт.

P32859

SCREW

M16 x 50

2шт.

P2037720

CAP

2шт.

P130486

O-RING

2.62 x 34.59-80

2шт.

P929835

TAPPET

PUSHER

2шт.

P30401

O-RING,2.5mm Thk x 18.5mm ID

2шт.

P34909

RUBBER WASHER

spring 22.5 x 11.2

38шт.

P29845

GUIDE

2шт.

P1343331

VALVE POPPET

2шт.

P945217

BACK-UP RING

JOINT

2шт.

P30401

O-RING,2.5mm Thk x 18.5mm ID

2шт.

P37411

PLUG

2шт.

P30444

O-RING,2.5mm Thk x 15mm ID, 80 Duro

2.5 x 15

2шт.

P1143379

SHIN

1шт.

P32954

SCREW

M10 x 65

4шт.

P32937

SCREW

M10 x 50

1шт.
