Запчасти Case 1085C (3-06) - ACCELERATOR LINKAGE, UPPER HYDRAULIC SWIVEL TO ENGINE (03) - FUEL SYSTEM

1

S517241

PIVOT

SWIVEL ASSEMBLY - hydraulic, upper, parts list Figure: 8-58

1шт.

2

218-1022

HYD CONNECTOR,7/16"-20, 37 Degree x 1/4"-18, NPTF

ADAPTER - straight, 7/16-20 flare x 1/4 inch PT

2шт.

3

S77467

HOSE

- 38 inch long, at upper hydraulic swivel

1шт.

222-1810

FITTING,17/32"-24 x 1/4" NPT

ADAPTER - compression, 3/8 tube OD x 1/4 inch female PT, Includes: Ref. 4 - 6

1шт.

4

NSS

NOT SOLD SEPARAT

BODY - adapter

1шт.

5

222-1860

SLEEVE,3/8" Tube, Comp

- spherical, 3/8 inch tube OD

1шт.

6

222-1865

NUT,17/32"-24, Sph Sleeve

NUT - hex, 3/8 tube OD x 17/32-24 inch

1шт.

7

222-2446

INSERT,1/4" Tube

SLEEVE - 3/8 inch tube OD

2шт.

8

S119824

PLASTIC-RUBBER TUBE,0.375" OD x 110" L

HOSE - 3/4 OD x 110 inch long, to slave cylinder, cut from bulk hose S118405, see below

1шт.

222-1847

ELBOW,90 Degree, 17/32"-24 x 1/8" NPT, Comp

- 90 degree, compression, 3/8 tube OD x 1/8 inch PT, Includes: Ref. 9 - 11

1шт.

9

NSS

NOT SOLD SEPARAT

BODY - elbow

1шт.

10

222-1860

SLEEVE,3/8" Tube, Comp

- spherical, 3/18 inch tube OD

1шт.

11

222-1865

NUT,17/32"-24, Sph Sleeve

NUT - hex, 3/8 tube OD x 17/32-24 inch

1шт.

12

S243750

CYLINDER

ASSEMBLY - accelerator slave, parts list Figure: 3-12

1шт.

13

425-155

JAM NUT,Jam, 5/16"-24, G5

- hex jam, 5/16 inch NF

1шт.

14

R51062

BALL JOINT

JOINT - ball, quick disconnect

1шт.

15

131-85

LOCK NUT,5/16"-24, GB

NUT - hex, self-locking, 5/16 inch NF

1шт.

16

S243396

LEVER

- actuating

1шт.

17

131-498

LOCK NUT,1/4"-28, GB

NUT - hex, self-locking, 1/4 inch NF

2шт.

18

A10329

BALL JOINT,1/4" - 28 x 1"

JOINT - ball

2шт.

19

425-154

JAM NUT,Jam, 1/4"-28, G5

- jam, hex, 1/4 inch NF

2шт.

20

S110842

ROD

- threaded, throttle control

1шт.

21

141-13

CLEVIS PIN,1/4" x 1.594"

PIN - clevis, 1/4 inch

1шт.

22

432-412

COTTER PIN,1/16" x 3/4"

PIN, SPLIT (COTTER), 1/16" x 3/4"

1шт.

23

S619452

BRACKET

- accelerator and air cleaner mounting

1шт.

24

814-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8, Full Thd

3шт.

25

892-11010

LOCK WASHER,M10

3шт.

26

S69862

BOLT

- shoulder, special

1шт.

27

496-21041

WASHER,13/32" x 13/16" x .089", HDN

- flat, 13/32 x 13/16 x 3/32", hardened

1шт.

S118405

HOSE,600.00", SAE J844

600.00", SAE J844

1шт.
