Артикул
Название
Примечание
Количество
1
S242698
BUCKET ASSEMBLY - 24 inch (610 mm), machinery item, order from Machinery Price List, Includes, Ref. 2 - 8
1шт.
1
S242699
BUCKET ASSEMBLY - 30 inch (762 mm), machinery item, order from Machinery Price List, Includes, Ref. 2 - 8
1шт.
1
S242700
BUCKET ASSEMBLY - 36 inch (914 mm), machinery item, order from Machinery Price List, Includes, Ref. 2 - 8
1шт.
1
S242701
BUCKET ASSEMBLY - 42 inch (1066 mm), high capacity, machinery item, order from Machinery Price List, Includes, Ref. 2 - 8
1шт.
2
S119061
EDGE
- cutting, for 24 inch (610 mm) bucket
1шт.
2
S119062
EDGE
- cutting, for 30 inch (762 mm) bucket
1шт.
2
S119262
EDGE
- cutting, for 36 inch (914 mm) standard capacity bucket
1шт.
2
S119063
EDGE
- cutting, for 36 inch (914 mm) high capacity bucket
1шт.
2
S119260
EDGE
- cutting, for 42 inch (1066 mm) high capacity bucket
1шт.
3
S615011
SHANK
- tooth, left-hand
1шт.
4
S615009
SHANK
- tooth, center
1шт.
5
S615010
SHANK
- tooth, right-hand
1шт.
S239750
ROLL PIN
PIN ASSEMBLY - roll, tooth point, Includes, Ref. 6 and 7
1шт.
6
138-310
LOCK PIN,1/2" x 3", Slotted
PIN, 1/2" x 3", Slotted
1шт.
7
REF
INSTRUCTION
PLUG - rubber, 3 inch (76 mm) long, cut from S119223, see below
1шт.
8
S615008
POINT
- tooth, standard
1шт.
9
S615024
POINT
- tooth, spade, optional
1шт.
10
S615025
POINT
- tooth, rock, optional
1шт.
11
S33993
CUTTER
- side, if used
2шт.
12
413-1248
BOLT,Hex, 3/4" - 10 x 3", Gr 5
- hex, 3/4 NC x 3 inch
6шт.
13
425-1012
NUT,3/4"-10, G5
- hex, 3/4 inch NC
6шт.
14
S617102
TURBINE
LINK ASSEMBLY - tool cylinder to bucket, Includes, Ref. 15 and 16
1шт.
15
S202134
BUSHING
- link
4шт.
16
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, straight, 1/8 PT x 21/32 inch
3шт.
17
S223986
PIN
-, Serial Range: link-bucket
1шт.
18
S61973
AXLE PIN
PIN - clevis, 1/2 diameter x 3-3/4 inch grip length
1шт.
19
132-48
COTTER PIN,1/8" x 1"
Pin, Split (Cotter), 1/8" x 1"
1шт.
S119223
RUBBER
PLUG - rubber, 48 inch (1219 mm) long strip
1шт.
Выбрано товаров: 28
