Артикул
Название
Примечание
Количество
1
S507956
LINK
EXTENSION - tool cylinder, outer
1шт.
2
S202134
BUSHING
- extension
2шт.
2a
S74929
SPACER
- bushing
1шт.
3
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, straight, 1/8 PT x 21/32 inch
2шт.
4
S61973
AXLE PIN
PIN - clevis, 1/2 diameter x 3-3/4 inch grip length
4шт.
5
432-1016
COTTER PIN,5/32" x 1"
5/32" x 1"
4шт.
6
S223986
PIN
- link, 12.35 inch (314 mm) long, used with S38354 and S38355 links
3шт.
6a
S242791
PIN
- link, 13.70 inch (348 mm) long, used with S517011 and S517012 links
3шт.
7
S38354
LINK
- tool cylinder extensions, right-hand, if used
2шт.
See illustration for identification of correct link.
1шт.
7a
S517012
LINK ASSY.
LINK - tool cylinder extensions, right-hand, if used
2шт.
See illustration for identification of correct link.
1шт.
8
S38355
LINK
- tool cylinder extensions, left-hand, if used
2шт.
See illustration for identification of correct link.
1шт.
8a
S517011
LINK ASSY.
LINK - tool cylinder extensions, left-hand, if used
2шт.
See illustration for identification of correct link.
1шт.
9
S10785
PIN
- clevis, 3/8 diameter x 3-1/4 inch grip length
2шт.
10
S206139
PIN
- outer extension to inner extension
1шт.
11
S507954
LINK
EXTENSION - tool cylinder, inner, Includes, Ref. 12 and 13
1шт.
12
S202134
BUSHING
- extension
2шт.
13
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, straight, 1/8 PT x 21/32 inch
2шт.
14
S54503
EXTENSION
- arm to tool, Includes, Ref. 15 - 17
1шт.
15
S202134
BUSHING
- link pivot
2шт.
16
S202137
BUSHING,50.73mm ID x 63.63mm OD x 63.5mm L
- tool pivot
2шт.
17
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, straight, 1/8 PT x 21/32 inch
3шт.
18
S213911
PIN
-, Serial Range: tool-arm
1шт.
19
432-816
COTTER PIN,1/8" x 1"
1/8" x 1"
1шт.
20
S61974
PIN
- clevis, 1/2 diameter x 4-1/4 inch grip length
1шт.
Выбрано товаров: 28
