Артикул
Название
Примечание
Количество
1
353-406
PLUG,Dome, .625" hole, Nylon
- nylon, 5/8 inch, if used
1шт.
2
S119987
GRIP
- handle, lever
1шт.
3
S515273
HANDLE
LEVER - control, hoist and auxiliary control, left-hand lever
1шт.
4
S239340
FLANGE
PLATE - boot
1шт.
5
S615715
BOOT
- left-hand control lever
1шт.
6
142-102
SCREW,Cross Oval Hd, #10 - 24 x 3/4"
- machine, oval head Phillips, No. 10 NC x 3/4 inch
2шт.
7
S117167
CLIP
- boot plate screw fastener
2шт.
8
S242226
HOUSING ASSY.
BLOCK - left-hand control lever mounting
1шт.
9
138-134
LOCK PIN,1/4" x 1", Slotted
PIN, , Control lever 1/4" x 1", Slotted
1шт.
10
138-136
LOCK PIN,1/4" x 1 1/4", Slotted
PIN, , Block 1/4" x 1 1/4", Slotted
1шт.
11
S242118
SWIVEL CONNECTION
PIN - pivot, control lever block
1шт.
12
138-136
LOCK PIN,1/4" x 1 1/4", Slotted
PIN, , Pivot pin 1/4" x 1 1/4", Slotted
1шт.
13
492-11038
LOCK WASHER,3/8"
4шт.
14
S236680
BALL JOINT
JOINT - ball, at control lever block
2шт.
15
S99329
STUD
ROD - control lever, Serial Range: block-shaft
2шт.
16
425-156
JAM NUT,Jam, 3/8"-24, G5
- hex, jam, 3/8 inch NF
4шт.
17
R47940
BALL JOINT
JOINT - ball, at shaft, replaces S116900 joint
2шт.
18
D55769
SPACER
- ball joint
2шт.
19
S514832
SHAFT
- pivot, hoist control
1шт.
20
S514831
SHAFT
- pivot, auxiliary control
1шт.
21
S238822
LEVER
- actuator
2шт.
22
138-140
LOCK PIN,1/4" x 1 3/4", Slotted
PIN, 1/4" x 1 3/4", Slotted
2шт.
23
213-41
ADJUSTABLE CLEVIS,3/8"-24
3шт.
24
A147652
PIN
LOCK - clevis
3шт.
25
425-156
JAM NUT,Jam, 3/8"-24, G5
- hex, jam, 3/8 inch NF
4шт.
26
S233229
ROD
- connecting, hoist control, at valve
1шт.
See Fig. 9-058, Refs. 3 and 3A, for connecting rods used with 30 and 60 inch cab risers See Fig. 9-058, Refs. 4 and 4A, for connecting rods used with 30 and 60 inch cab risers.
1шт.
27
S229509
ROD
- connecting, auxiliary control, used on models with Y-boom
1шт.
See Fig. 9-058, Refs. 3 and 3A, for connecting rods used with 30 and 60 inch cab risers.See Fig. 9-058, Refs. 4 and 4A, for connecting rods used with 30 and 60 inch cab risers.
1шт.
28
S238834
ROD
- connecting, auxiliary control, at valve
1шт.
29
S10767
PIN
- clevis, 3/8 x 1-1/8 inch
1шт.
30
432-1012
COTTER PIN,5/32" x 3/4"
5/32" x 3/4"
1шт.
31
S514438
BAR
- pivot shaft support
2шт.
32
413-656
BOLT,Hex, 3/8" - 16 x 3-1/2", Gr 5
- hex, 3/8 NC x 3-1/2 inch
4шт.
33
495-21044
WASHER,3/8"
(flat, 7/16 x 1 x 5/64 inch) 3/8"
3шт.
34
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
(Flat, 13/32 x 13/16 x 1/16") 3/8", SAE
4шт.
35
131-52
NUT,3/8"-16, GC
NUT - light hex, self-locking, 3/8 inch NC
4шт.
Выбрано товаров: 37
