Запчасти Case W9B (250) - DECALS (09) - CHASSIS

Схема запчастей Case W9B - (250) - DECALS (09) - CHASSIS

Артикул

Название

Примечание

Количество

A55818

DECAL

SET - W9, Series "B", Includes: Ref. 1 - 6

1шт.

1

321-706

DECAL

- hood, R.H. side

1шт.

2

321-707

DECAL

- hood, L.H. side

1шт.

3

321-705

DECAL

- W9, Series "B" (Not illustrated)

2шт.

4

321-649

DECAL

- mechanical range shift

1шт.

5

321-648

DECAL

- rear axle shift

1шт.

6

321-12

DECAL

- engine valve cover

1шт.

B17101

DECAL

SET - W10, Series "B", Includes: Ref. 1 - 6

1шт.

1

321-706

DECAL

- hood, R.H. side

1шт.

2

321-707

DECAL

- hood, L.H. side

1шт.

3

321-752

DECAL

- W10, Series "B"

2шт.

4

321-649

DECAL

- mechanical range shift

1шт.

5

321-648

DECAL

- rear axle shift

1шт.

6

321-12

DECAL

- engine valve cover

1шт.

7

A17711

DECAL

- 4-in-1 bucket level

1шт.

8

A17710

DECAL

- 4-in-1 bucket clam opening

1шт.

9

321-815

DECAL - engine data (A401 diesel)

1шт.

10

321-827

DECAL - engine data (A377 gas)

1шт.

11

A19277

PLATE ASSY.

PLATE - bucket control, 2 spool

1шт.

12

A18406

PLATE ASSY.

PLATE - bucket control, 3 spool

1шт.

Выбрано товаров: 20
