Артикул
Название
Примечание
Количество
1
A18886
PEDAL - brake, R.H., Includes: Ref. 2
1шт.
2
A30845
BUSHING
- pedal
2шт.
3
A17383
PEDAL - brake, L.H., Includes: Ref. 4
1шт.
4
A30845
BUSHING
- pedal
2шт.
5
A17384
SHAFT - mounting, brake pedal
1шт.
6
A27275
LOCK PIN - pedal shaft
1шт.
7
132-93
COTTER PIN,3/16" x 1 1/4"
Pin, Split (Cotter), 3/16" x 1 1/4"
1шт.
8
195-553
WASHER,1", SAE
- plain (1")
1шт.
9
A18905
BRACKET - stop, brake pedal
1шт.
10
13-636
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5
1шт.
11
25-146
JAM NUT,Jam, 3/8"-16, G5
- hex., jam (3/8" - 16 NC)
2шт.
12
13-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd
2шт.
13
92-6
LOCK WASHER,3/8"
2шт.
14
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
2шт.
15
A26953
CLIP
BRACKET - spring, pedal return
2шт.
16
13-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
2шт.
17
92-6
LOCK WASHER,3/8"
2шт.
18
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
2шт.
19
A10436
VALVE SPRING
SPRING - pedal return
2шт.
20
A18893
ARM - brake, Serial Range: pedal-valve
1шт.
21
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
1шт.
22
92-6
LOCK WASHER,3/8"
1шт.
23
113-438
BOLT,Hex, 1/2" - 13 x 2-1/4", SST
1шт.
24
25-148
JAM NUT,Jam, 1/2"-13, G5
- hex, jam (1/2"-13 NC)
1шт.
25
A18899
ROD
- connecting, Serial Range: arm-valve
1шт.
26
213-3
ADJUSTABLE CLEVIS,5/16"-24
YOKE - rod end
1шт.
27
25-115
NUT,5/16"-24, G5
- hex (5/16"-24 NF)
1шт.
28
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, , Yoke 5/16" x .940"
1шт.
115
NUT - hex. (5/16" - 24 NF)
1шт.
29
95-5
WASHER,3/8" x 7/8" x .083"
- plain (5/16")
1шт.
30
132-5
COTTER PIN,1/16" x 1/2"
Pin, Split (Cotter), 1/16" x 1/2"
2шт.
31
A18891
LOCK VALVE
VALVE - clutch control (Parts list Figure 128)
1шт.
32
A18892
BRACKET - mounting, clutch control
1шт.
33
13-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
HHCS - 3/8" - 16 NC x 1-1/2"
2шт.
34
92-6
LOCK WASHER,3/8"
2шт.
35
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
2шт.
36
169-107
SCREW,Sl Fil Hd, #10 - 24 x 2"
- machine, slotted head (#10 - 24 NC x 2")
3шт.
37
92-3
LOCK WASHER,#10
WASHER, LOCK, #10
3шт.
38
129-7
NUT,Hex, #10 - 24
- hex. (#10 - 24 NC)
3шт.
39
A18885
PLATE - brake pedal mounting, L.H.
1шт.
40
A18888
PLATE - mounting, brake pedal and cylinder, R.H.
1шт.
41
A18889
PLATE - mounting, cylinder (Inner)
1шт.
42
13-820
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd
6шт.
43
92-8
LOCK WASHER,1/2"
6шт.
44
25-108
NUT,1/2"-13, G5
- hex. (1/2" - 13 NC)
6шт.
45
13-656
BOLT,Hex, 3/8" - 16 x 3-1/2", Gr 5
HHCS - 3/8" - 16 NC x 3-1/2"
2шт.
46
92-6
LOCK WASHER,3/8"
2шт.
47
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
2шт.
49
A18526
ROD
PUSH ROD - master cylinder
1шт.
50
25-157
JAM NUT,Jam, 7/16"-20, G5
- hex., jam (7/16" - 20 NF)
1шт.
51
95-7
WASHER,7/16"
- plain () 7/16"
1шт.
52
A12442
YOKE - push, Serial Range: rod-pedal
1шт.
53
A27094
PIN
- yoke, brake pedal
1шт.
54
132-48
COTTER PIN,1/8" x 1"
Pin, Split (Cotter), 1/8" x 1"
1шт.
55
A18890
CONNECTOR, ELEC
CONNECTOR - master cylinder to brake lines
1шт.
56
A12864
BOLT
- special, Serial Range: connector-cylinder
1шт.
57
33260
GASKET
- connector to bolt (Outer)
1шт.
58
51200242
SEAL,15.24mm ID x 20.64mm OD x 0.81mm Thk
- connector to master cylinder (Inner)
1шт.
59
A18980
PIPE
TUBE - master cylinder to Hydrovac cylinder
1шт.
60
A18988
TUBE
- master cylinder to clutch control valve
1шт.
61
222-1012
HYD CONNECTOR,7/16"-24 Inv Fl x 1/8" NPT
CONNECTOR - clutch control tube to tee and transmission tube to valve
2шт.
62
217-55
TEE,1/8"-27 NPTF Fem Run x 1/8"-27 NPTF Male Br
- clutch control tube and switch to control valve
1шт.
63
A12491
SWITCH
ASSY - brake, stop light
1шт.
64
A18977
TUBE - clutch control valve to transmission control valve
1шт.
65
NSS
NOT SOLD SEPARAT
BODY - master cylinder
1шт.
66
A19918
CAP
- filler, master cylinder
1шт.
67
A19755
GASKET
- filler cap, master cylinder
1шт.
68
A19803
SEAL
SPRING - piston return, master cylinder
1шт.
69
A19759
PLATE
- stop, master cylinder
1шт.
A19919
KIT
- cylinder repair, master cylinder, Includes: Ref. 70 - 73
1шт.
70
NSS
NOT SOLD SEPARAT
PISTON ASSEMBLY - cylinder, master
1шт.
71
NSS
NOT SOLD SEPARAT
CUP - piston, master cylinder
1шт.
72
NSS
NOT SOLD SEPARAT
LOCKWIRE - stop plate, master cylinder
1шт.
73
A19916
BOOT
- protective, master cylinder
1шт.
74
G10943
DUST CAP
CAP - rubber, push rod, master cylinder
1шт.
56
A12864
BOLT
- special, connector to cylinder, master cylinder
1шт.
Выбрано товаров: 78
