Артикул
Название
Примечание
Количество
1
13-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
1шт.
2
92-5
LOCK WASHER,5/16"
med sect. 5/16"
1шт.
3
A13904
CLIP - rod, fuel shutoff
1шт.
4
A17253
ROD
- fuel shutoff
1шт.
5
25-154
JAM NUT,Jam, 1/4"-28, G5
- hex, jam (1/4"-28 NF)
1шт.
6
213-2
ADJUSTABLE CLEVIS,1/4"-28 x 2"
YOKE - rod (1/4")
1шт.
7
141-2
CLEVIS PIN,1/4" x .770"
PIN - yoke
1шт.
8
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
1шт.
9
138-130
LOCK PIN,1/4" x 3/4", Slotted
PIN, 1/4" x 3/4", Slotted
1шт.
10
A8018
STEP BOLT
STUD - fuel shutoff lever
1шт.
11
A12421
LEVER
- stop, foot throttle
1шт.
12
A19103
SHAFT
THROTTLE AND SHAFT - foot control
1шт.
13
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
4шт.
14
92-5
LOCK WASHER,5/16"
med sect. 5/16"
4шт.
15
A17249
SUPPORT
- throttle cross shaft
2шт.
16
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
NIPPLE, LUBE, 90º, 1/8" NPT x .84" lg
2шт.
17
413-632
BOLT,Hex, 3/8" - 16 x 2", Gr 5
- 3/8" - 16 NC x 2"
1шт.
18
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
1шт.
19
135-341
GROOVED PIN,3/16" x 1", Type F
Pin, Grooved, , Lever 3/16" x 1", Type F
1шт.
20
A17250
SUPPORT
LEVER - foot throttle
1шт.
21
25-155
JAM NUT,Jam, 5/16"-24, G5
- hex., jam (5/16" - 24 NF)
2шт.
22
193-9
LOCK WASHER,Ext Tooth, 5/16"
WASHER, LOCK, Ext Tooth, 5/16"
1шт.
23
A19105
BALL JOINT
- throttle rod
1шт.
24
A19106
ROD - throttle, front
1шт.
25
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
1шт.
26
A12031
CLIP - retaining, rod to side plate
1шт.
27
A17255
SPACER - retaining clip
1шт.
28
92-5
LOCK WASHER,5/16"
med sect. 5/16"
1шт.
29
25-106
NUT,3/8"-16, G5
- hex. (5/16" - 18 NC)
1шт.
30
A12505
BALL JOINT
JOINT - swivel, throttle connector
1шт.
31
A19113
LEVER - throttle, rear (Outer)
1шт.
32
193-9
LOCK WASHER,Ext Tooth, 5/16"
WASHER, LOCK, Ext Tooth, 5/16"
1шт.
33
25-155
JAM NUT,Jam, 5/16"-24, G5
- hex., jam (5/16" - 24 NF)
1шт.
34
138-73
LOCK PIN,5/32" x 3/4", Slotted
PIN, 5/32" x 3/4", Slotted
2шт.
35
A19109
SHAFT - cross, throttle lever
1шт.
36
A19112
LEVER - throttle, rear (Inner)
1шт.
37
13-426
BOLT,Hex, 1/4" - 20 x 1-5/8", Gr 5
HHCS - 1/4" - 20 NC x 1-5/8"
4шт.
38
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
4шт.
39
A19110
SUPPORT - cross shaft, rear throttle
2шт.
40
A19111
SPACER - cross shaft support
2шт.
41
A22619
SPRING
- return, throttle
1шт.
42
A19959
BRACKET - retaining, throttle spring
1шт.
43
25-154
JAM NUT,Jam, 1/4"-28, G5
- hex, jam (1/4"-28 NF)
4шт.
44
193-8
LOCK WASHER,Ext Tooth, 1/4"
WASHER, LOCK, Ext Tooth, 1/4"
2шт.
45
A10329
BALL JOINT,1/4" - 28 x 1"
- rear throttle rod
2шт.
46
A19107
ROD - throttle control, rear
1шт.
47
A15213
BOLT - retaining, throttle lever
1шт.
48
193-30
LOCK WASHER,Int Tooth, 3/8"
WASHER, LOCK, Int Tooth, 3/8"
1шт.
49
A16507
LEVER - throttle control
1шт.
50
A24553
ROD - throttle, Serial Range: lever-governor
1шт.
51
132-25
COTTER PIN,3/32" x 5/8"
Pin, Split (Cotter), 3/32" x 5/8"
1шт.
52
84-44
SET SCREW,Hex Soc, 1/4"-28 x 1/4"
SCREW - set, hex. socket head (1/4" - 20 NC x 1/4")
1шт.
53
A20846
COLLAR
- throttle rod
1шт.
54
A10868
DECAL
SPRING - governor
1шт.
55
132-46
COTTER PIN,1/8" x 3/4"
Pin, Split (Cotter), 1/8" x 3/4"
1шт.
56
A10326
BALL JOINT
- governor to carburetor rod
1шт.
57
A21306
ROD -, Serial Range: governor-carburetor
1шт.
58
132-5
COTTER PIN,1/16" x 1/2"
Pin, Split (Cotter), 1/16" x 1/2"
1шт.
Выбрано товаров: 58
