Артикул
Название
Примечание
Количество
A17650
FILTER
AIR CLEANER - dry type, Includes: Ref. 1 - 10
1шт.
1
A17745
NUT
NUT - wing, cover retainer
1шт.
2
A17744
GROMMET
- cover sealing
1шт.
3
A17743
X
COVER - air cleaner body
1шт.
4
A17741
AIR CLEANER
ELEMENT - filter, outer
1шт.
5
A17748
GASKET
NUT - wing, element retainer
1шт.
6
A17747
PLATE ASSY.
COVER - inner filter element
1шт.
7
A17748
GASKET
- filter element
1шт.
8
A17742
AIR CLEANER
ELEMENT - filter, inner
1шт.
9
NSS
NOT SOLD SEPARAT
BODY - air cleaner
1шт.
10
A17749
GASKET
- air cleaner, Serial Range: body-bracket
1шт.
11
A19088
TUBE AND BRACKET - mounting, air cleaner
1шт.
12
92-5
LOCK WASHER,5/16"
med sect. 5/16"
6шт.
13
25-115
NUT,5/16"-24, G5
- hex (5/16"-24 NF)
6шт.
14
A17652
ELECTRICAL GAUGE
GAUGE - warning, air cleaner
1шт.
15
D36264
FITTING
ADAPTER - filtered, Serial Range: gauge-bracket
1шт.
16
13-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
4шт.
17
92-6
LOCK WASHER,3/8"
med. sect. 3/8"
4шт.
18
214-260
HOSE CLAMP,#36, 1.81" - 2.75", Type F Worm
- hose to bracket and carburetor #36, 1.81/2.75 Type F Worm
2шт.
19
A19083
HOSE
- mounting, Serial Range: bracket-carburetor
1шт.
20
A19082
SLEEVE -, Serial Range: carburetor-hose
1шт.
21
A61277
CAP
PRE-SCREENER - air cleaner (Late production), oil bath and cleaner gas engine
1шт.
21
A10872
CAP
PRE-SCREENER - air cleaner (Early production), oil bath and cleaner gas engine
1шт.
A21415
AIR CLEANER - oil bath and cleaner gas engine, Includes: Ref. 22 - 26
1шт.
22
A22344
CUP - oil bath and cleaner gas engine
1шт.
23
129-404
WING NUT,1/4"-20
NUT - wing, element retaining (1/4" - 20 NC), oil bath and cleaner gas engine
1шт.
24
A22345
ELEMENT - filter, oil bath and cleaner gas engine
1шт.
25
A22336
BAND - retaining, oil cup, oil bath and cleaner gas engine
1шт.
26
NSS
NOT SOLD SEPARAT
BODY - air cleaner, oil bath and cleaner gas engine
1шт.
27
A10867
CLAMP - mounting, air cleaner, oil bath and cleaner gas engine
2шт.
28
13-610
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd
Oil bath and cleaner gas engine Hex, 3/8"-16 x 5/8", G5, Full Thd
4шт.
29
92-6
LOCK WASHER,3/8"
oil bath and cleaner gas engine 3/8"
4шт.
30
214-264
HOSE CLAMP,#52, 2.81" - 3.75", Type F Worm
CLAMP - air cleaner to hose, oil bath and cleaner gas engine
2шт.
31
L10236
HOSE
- air cleaner to carburetor (3" I.D. x 32" long) Used with A32617 carburetor, oil bath and cleaner gas engine
1шт.
31
A19990
HOSE - air cleaner to carburetor (3" I.D. x 52" long) Used with A24552 carburetor, oil bath and cleaner gas engine
1шт.
32
A19992
SLEEVE - hose to carburetor, oil bath and cleaner gas engine
1шт.
33
214-258
HOSE CLAMP,#28, 1.31" - 2.25", Type F Worm
- sleeve to carburetor, oil bath and cleaner gas engine #28, 1.31/2.25 Type F Worm
1шт.
Выбрано товаров: 37
