Артикул
Название
Примечание
Количество
1
A23681
COVER ASSY
. - cylinder head, Includes: Ref. 2
3шт.
2
131-114
SPRING NUT,Rtnr, 1/4" - 20, 0.25" High
NUT - speed, 1-1/4" N.C. retainer type
1шт.
3
A57595
CYLINDER HEAD GASKET
-, Serial Range: cover-head
3шт.
4
A28184
BEARING CUP
TUBE - breather
1шт.
5
75-436
SCREW,Rd, 1/4" - 20 x 2 1/4"
- 1/4 x 2-1/4" N.C. rd. hd.
3шт.
6
A34133
GASKET
- fiber, tube screw
3шт.
7
A23685
GASKET
- rubber, Serial Range: tube-cover
3шт.
8
A23686
BRACKET
- breather tube (On oil pan)
1шт.
9
A9936
BOLT - bracket (3/8 x 1-1/8" N.C. hex.)
2шт.
10
A27882
STUD - cover & rocker brkt. (w/7/16" N.F. top thread) (Used prior to eng. SN 2095635)
6шт.
11
A57458
STUD
- cover & rocker brkt. (w/7/16" N.F. top thread) (1st used eng. SN 2095635) (Order A57990 & 25-107)
6шт.
11
A57990
STUD
- cover & rocker brkt. (w/7/16" N.C. top thread) (1st used eng. SN 2095635)
6шт.
12
A23684
GASKET
GASKET - rubber, cover nut
6шт.
13
A23683
WASHER
- dished, cover nut (15/32 x 1-25/64")
6шт.
14
25-117
NUT,7/16"-20, G5
- cover, 7/16" N.F. hex. (Use w/A27882 or A57458)
6шт.
14
25-107
NUT,7/16"-14, G5
- cover, 7/16" N.C. hex. (Use w/A57990)
6шт.
20
A33643
HEAD (CYLINDER)
HEAD ASSY. - (Casting no. A33612) (1st used eng ser. no. 2095635), Includes: Ref. 22 - 28
3шт.
21
A20956
HEAD (CYLINDER)
HEAD ASSY. - (Casting no. A20957) (Used prior to eng. ser. no. 2095635), Includes: Ref. 22 - 28
3шт.
22
NSS
NOT SOLD SEPARAT
GUIDE - exhaust valve (Order ref. 35)
2шт.
23
NSS
NOT SOLD SEPARAT
GUIDE - intake valve (Order ref. 36)
2шт.
24
NSS
NOT SOLD SEPARAT
INSERT - valve seat (Order ref. 37)
2шт.
25
A34124
PLUG,Cup, 1 5/8", Stainless
- head (1-5/8" cup type)
2шт.
26
A11810
PIN,3.19mm OD x 6.99mm L
- powrcel (1/8 x 17/64")
2шт.
27
A10678
STUD
- injector
2шт.
28
A10679
GASKET
- stud (23/32 x 29/32 x 1/32" copper)
2шт.
30
A23118
GASKET
-, Serial Range: head-block
3шт.
31
A27410
O-RING,0.487" ID x 0.693" OD x 0.103"
"O" RING - oil passage (1/2 x 11/16 x 3/32")
3шт.
32
A7669
RING
- rubber, water passage (7/8 x 1-3/32 x 5/64")
6шт.
33
A23355
BOLT
- head to block (9/16 x 6" N.C. hex.)
27шт.
35
A21674
GUIDE
S - exhaust valve (Set of 2)
3шт.
36
A21671
GUIDE
S - intake valve (Set of 2)
3шт.
37
A57484
INSERT
S - exhaust valve seat (Set of 2)
3шт.
A22978
BODY
power cell
1шт.
Выбрано товаров: 33
