Запчасти Case W7E (088) - LIGHTS, FRONT AND REAR LIGHTS - 12 VOLT, FRONT AND REAR (04) - ELECTRICAL SYSTEMS

1

D42097

LIGHT - front and rear - 12 volt, Includes: Ref. 2 - 4

4шт.

2

A24572

LAMP

- sealed unit - 12 volt

1шт.

3

A25213

RETAINER

- sealed unit (Rubber)

1шт.

4

A25214

LIGHT

BODY ASSEMBLY

1шт.

182-83

SCREW

- #8 - 32 x 5/16" mach., pan hd. slotted

1шт.

5

A34046

BRACKET

- mounting

4шт.

6

10923

WASHER

- concave, Serial Range: light-bracket

8шт.

7

192-23

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

4шт.

8

129-105

NUT,Hex, 1/2" - 13, Gr 5

Light mounting 1/2"-13, G5

4шт.

9

113-209

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

Bracket Hex, 3/8"-16 x 1 1/2", G5

4шт.

10

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

11

129-105

NUT,Hex, 1/2" - 13, Gr 5

- bracket bolt, 3/8" N.C. hex Z.P.

4шт.
