Запчасти Case W7 (122) - ALTERNATOR KIT, (DIESEL), FIELD INSTALLED ON SOME UNITS, PRIOR TO SN 9804816 (04) - ELECTRICAL SYSTEMS

1

A41340

ALTERNATOR

- 55 amp

1шт.

1

104022A1R

REMAN-ALTERNATOR

Remanufactured Alternator

1шт.

1

104022A1C

CORE-ALTERNATOR

Return Number, 12 VOLT, 55 Amp Alternator

1шт.

2

A41057

PULLEY

- alternator

1шт.

A21457

SET OF BELTS,50.50" L

SET OF 2 BELTS , Matched, Fan, Not shown 50.50" L

1шт.

3

A34704

BRACKET

- alternator mounting

1шт.

4

13-652

BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5

HHCS - 3/8" - 16 NC x 3-1/4"

1шт.

5

13-1244

BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5

1шт.

6

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

1шт.

7

L11351

REGULATOR

- voltage

1шт.

8

173-257

SCREW,Phil Rnd Hd, #10 - 24 x 1/2"

- Phillips, #10 - 24 NC x 1/2"

3шт.

9

L12281

HARNESS

- wiring, R.H.

1шт.

10

L12280

HARNESS

- wiring, rear

1шт.

11

L12289

CLIP

- L12281 harness

1шт.

12

L12282

HARNESS

- wiring, instrument panel

1шт.

13

L11541

CABLE TIE,203.2mm L, Nylon

STRAP - harness

2шт.

14

A55699

ELECTRICAL GAUGE

AMMETER - 60 amp

1шт.

15

A56181

ELECTRICAL WIRE

WIRE - circuit, Serial Range: breaker-ground

1шт.

16

L11352

ELECTRICAL WIRE

WIRE - jumper, front lights

1шт.

17

L12279

HARNESS

- wiring (L.H.)

1шт.

18

49838

CLAMP

CLIP - harness

1шт.

19

13-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

1шт.

20

195-18

WASHER,1/4"

- plain () 1/4"

1шт.

21

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

22

25-104

NUT,1/4"-20, G5

1шт.

23

L12289

CLIP

- harness

1шт.

24

L11393

CABLE

-, Serial Range: battery-ground

1шт.

25

L11391

CABLE

- battery, jumper

1шт.

26

L11392

CABLE

- battery to starter solenoid

1шт.

27

L12290

CABLE

- heater solenoid to manifold heater

1шт.

28

L11343

BREAKER

CIRCUIT BREAKER

1шт.

29

221-1053

BUSHING

- reducing, 3/8" x 1/4"

1шт.

30

A19332

TEE

- street, special

1шт.

31

221-1051

REDUCER,Hex, 1/4" x 1/8" NPT

BUSHING - reducing, 1/4" x 1/8"

1шт.

32

D28798

SWITCH

- pressure

1шт.

33

49838

CLAMP

CLIP - harness

1шт.

34

13-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

1шт.

35

195-18

WASHER,1/4"

- plain () 1/4"

1шт.

36

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

37

25-104

NUT,1/4"-20, G5

1шт.

38

A22880

CLIP

- wiring

3шт.

39

L11394

CABLE - ground, Serial Range: engine-chassis

1шт.

40

A7922

CLIP

- wiring

1шт.
