Запчасти Case W5A (140) - REAR AXLE - SPINDLES AND TIE RODS (09) - CHASSIS

Схема запчастей Case W5A - (140) - REAR AXLE - SPINDLES AND TIE RODS (09) - CHASSIS

Артикул

Название

Примечание

Количество

1

A13846

AXLE ASSY. - rear, Includes: Ref. 2

1шт.

2

A13845

BUSHING

- pivot pin, 1-1/2 x 1-3/4 x 1"

2шт.

3

A13388

PIN - pivot, rear axle

1шт.

4

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - grease, 1/8" P.T., str.

2шт.

5

13-816

BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd

Pivot pin Hex, 1/2"-13 x 1", G5, Full Thd

1шт.

6

92-8

LOCK WASHER,1/2"

1шт.

7

A13390

ROD - radius, rear axle

1шт.

8

A26659

STEP BOLT

BOLT - shoulder, radius, Serial Range: rod-axle

2шт.

9

193-37

LOCK WASHER,Int Tooth, 1"

WASHER, LOCK, Int Tooth, 1"

2шт.

10

25-1116

NUT,1"-14, G5

- 1" N.F. hex.

2шт.

11

A15389

BLOCK ASSY. - pivot, radius rod, Includes: Ref. 12

1шт.

12

A27726

BUSHING - block, 1-1/2 x 1-3/4 x 1-5/16"

2шт.

13

A15521

SPACER - block

1шт.

14

A13405

SHIM - block (.0598")

2шт.

15

14-1272

BOLT,Hex, 3/4" - 16 x 4-1/2", Gr 5

- block, 3/4 x 4-1/2" N.F. hex.

2шт.

16

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

2шт.

17

25-1112

NUT,3/4"-16, G5

- 3/4" N.F. hex.

2шт.

18

A13402

PIN - pivot, radius rod

1шт.

19

92-20

WASHER,1 1/4"

LOCK, 1 1/4"

1шт.

20

25-1520

NUT

- 1-1/4" N.F. half hex.

1шт.

21

A13406

WASHER

- pivot pin, 17/32 x 2-3/8 x 12 Ga.

6шт.

22

A13407

WASHER - lock, pivot pin nut

1шт.

23

25-1524

JAM NUT,Jam, 1 1/2"-12, G5

- pivot pin, 1-1/2" N.F. half hex

1шт.

28

A7789

SPINDLE - steering

2шт.

29

A27827

NEEDLE BEARING,Needle, 31.75mm ID x 38.1mm OD x 31.75mm W

BEARING - needle, king pin

4шт.

30

A26658

THRUST BEARING,1.26" ID x 2.1875" OD x 0.63"

BEARING - thrust, spindle

2шт.

31

A27826

SPLIT PIN/SAFETY PIN

PIN - king, rear axle

2шт.

32

A27825

PLUG

- spindle

4шт.

33

219-36

LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF

FITTING - grease, 1/8" P.T., 45 degrees

4шт.

34

A26490

LOCK ASSY

LOCK - king pin

2шт.

35

92-8

LOCK WASHER,1/2"

2шт.

36

25-118

NUT,1/2"-20, G5

- lock pin, 1/2" N.F. hex.

2шт.

37

A13400

ARM - steering, right hand

1шт.

38

A13585

ARM ASSY. - steering, left hand, Includes: Ref. 39

1шт.

39

A23418

BALL

- rear drag link

1шт.

40

126-129

WOODRUFF KEY,#C, 5/16" x 1 1/8", HT

Steering arm #C, 5/16" x 1 1/8", HT

2шт.

41

92-16

LOCK WASHER,1"

WASHER, LOCK, 1"

2шт.

42

25-1116

NUT,1"-14, G5

- steering arm, 1" N.F. hex.

2шт.

48

A9593

TIE ROD - steering

1шт.

49

A28419

END ASSY.

- tie rod, right hand, Includes: Ref. 50

1шт.

50

G46043

COVER

- dust, tie rod end

1шт.

51

A28704

END

ASSY. - tie rod, left hand, Includes: Ref. 52

1шт.

52

G46043

COVER

- dust, tie rod end

1шт.

53

A27080

CLAMP

- tie rod ends

2шт.

54

25-139

SLOTTED NUT,9/16"-18, G5

NUT - tie rod ends, 9/16" N.F. sltd.

2шт.

55

132-48

COTTER PIN,1/8" x 1"

Pin, Split (Cotter), 1/8" x 1"

2шт.

56

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - grease, 1/8" straight

1шт.

Выбрано товаров: 47
