Запчасти Case W5 (090) - STEERING GEAR (05) - STEERING

A13568

GEAR ASSY. - steering (Not shown), Includes: Ref. 1 - 32

1шт.

1

A14554

HOUSING ASSY., Includes: Ref. 2 - 4

1шт.

2

G10725

BUSHING

- housing, 1 x 1-1/4 x 1"

2шт.

3

A18322

SEAL

- oil

1шт.

4

A18323

COVER ASSY

COVER - housing end and horn wire tube

1шт.

5

A14556

LEVERSHAFT ASSY., Includes: Ref. 6 and 7

1шт.

6

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

1шт.

7

25-1512

JAM NUT,Jam, 3/4"-10, G5

- 3/4" N.F. half hex.

1шт.

8

A14557

COVER ASSY. - side, Includes: Ref. 9 - 11

1шт.

9

A18330

SCREW - levershaft adjusting

1шт.

10

25-158

JAM NUT,Jam, 1/2"-20, G5

- jam, 1/2" N.F. hex. adjusting screw

1шт.

11

L30219

RING - adjusting screw sealing

1шт.

12

A14558

GASKET

- side cover

1шт.

13

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

Cover Hex, 5/16"-18 x 1", G5, Full Thd

4шт.

14

A31046

WASHER

- cover bolts, 21/64 x 9/16 x 18 Ga. copper

4шт.

15

A14555

WORM GEAR ASSY. - steering

1шт.

16

L30422

KIT

- bearing, Includes: Ref. 17 and 18

2шт.

17

NSS

NOT SOLD SEPARAT

RACE - ball cup

1шт.

18

NSS

NOT SOLD SEPARAT

RETAINER & BALL ASSY.

1шт.

19

A14559

COVER - housing, upper

1шт.

20

A18331

SHIM,.002" Thk

Upper cover .002" Thk

1шт.

20

A18332

SHIM,.003" Thk

Upper cover .003" Thk

1шт.

20

A18333

SHIM,.010" Thk

Upper cover .010" Thk

1шт.

21

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Upper cover Hex, 5/16"-18 x 3/4", G5, Full Thd

3шт.

22

A31046

WASHER

- cover bolts, 21/64 x 9/16 x 18 Ga. copper

3шт.

23

A14561

SLEEVE ASSY. - steering shaft, Includes: Ref. 24 - 26

1шт.

24

A30610

BUSHING

BEARING - steering shaft

1шт.

25

A30713

VALVE SPRING

SPRING - bearing

1шт.

26

A18325

SEAT

CAP - sleeve & spring seat

1шт.

27

A31045

CLAMP

- sleeve to upper cover

1шт.

28

14-532

BOLT,Hex, 5/16" - 24 x 2", Gr 5

- 5/16 x 2" N.F. hex.

1шт.

29

193-29

LOCK WASHER,Int Tooth, 5/16"

WASHER, LOCK, Int Tooth, 5/16"

1шт.

30

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

1шт.

31

A14567

JAM NUT

- steering wheel retaining

1шт.

32

221-12

PLUG,Sq Hd, 1/4"-18

- housing, 1/4" P.T., sq. hd.

1шт.

35

A13567

WHEEL (STEERING)

WHEEL - steering (Order L16338, A19185 wire, and A16843 button)

1шт.

36

L16338

WHEEL

- steering

1шт.

37

A13419

BRACKET - steering column support

1шт.

38

A13430

CLAMP

- steering column

1шт.

39

14-612

BOLT,Hex, 3/8" - 24 x 3/4", Gr 5, Full Thd

Bracket & clamp Hex, 3/8"-24 x 3/4", G5, Full Thd

4шт.

40

92-6

LOCK WASHER,3/8"

4шт.

41

25-116

NUT,Hex, 3/8"-24, G5

- 3/8" N.F. hex.

2шт.

42

A14563

ARM - drop, steering (Replaces A19417)

1шт.

43

A14568

BUTTON

- horn (Rubber)

1шт.

43

A16843

BUTTON

- horn (Metal)

1шт.

44

A14570

DISC - contact (In button)

1шт.

45

A14574

WIRE - horn (w/rubber button)

1шт.

45

A19185

ELECTRICAL WIRE

WIRE - horn (w/metal button)

1шт.

46

A14572

INSULATION - wire (Rubber ferrule)

1шт.

47

A14569

CUP - horn button spring retaining

1шт.

48

A14571

SPRING - horn button

1шт.

49

221-1412

ELBOW,90 Degree, 1/4"-27, NPT

1шт.
