Запчасти Case W36 (7-230) - CLUTCH CUTOUT (07) - BRAKES

1

L73042

VALVE, BRAKE

TREADLE AND VALVE ASSEMBLY - brake, left-hand, parts list Figure 7-244

1шт.

2

L71225

HOSE ASSY.,0.25" ID x 72.00", SAE J1402 Type B

HOSE ASSY, 0.25" ID x 72.00", SAE J1402, Type B, Clutch Cutout

1шт.

3

218-441

HYD CONNECTOR,7/16" - 20 Male JIC x 1/8" - 27 Male NPTF

ADAPTER - straight

1шт.

4

221-87

REDUCER,1/2" NPT x 1/8" NPT

- 1/2" x 1/8" NPT

1шт.

222-2640

ELBOW,90 Degree, 7/16"-24 x 1/8" NPT, Comp

FITTING - compression, 90 degree elbow, Includes: Ref. 5 - 7

2шт.

5

NSS

NOT SOLD SEPARAT

BODY - elbow

1шт.

6

222-2600

NUT

COMPRESSION NUT - elbow

1шт.

7

222-2610

SLEEVE

- elbow

1шт.

8

L110859

TUBE,6.35 mm OD x 254 mm L

- 1/4" (6 mm) ID x 10" (254 mm) long, cut from L108947

1шт.

222-2625

FITTING,7/16"-24 x 1/8" NPT, Comp

- compression, straight, Includes: Ref. 9 - 11

1шт.

9

NSS

NOT SOLD SEPARAT

BODY - fitting

1шт.

10

222-2600

NUT

COMPRESSION NUT - fitting

1шт.

11

222-2610

SLEEVE

- fitting

1шт.

12

217-1071

HYD CONNECTOR,1/4" - 18NPTF x 1/8" - 27 NPTF

ADAPTER - straight

1шт.

13

L109922

VALVE

- three way pilot, parts list Figure 7-250

1шт.

14

218-481

ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 1/8" - 27 Male NPTF

- 90 degree

1шт.

15

L110858

TUBE,1335 mm L

- 1/4" (6 mm) ID x 52-1/2" (1335 mm) long, cut from L108947

1шт.

L108947

TUBE,4.32 mm ID x 6.35 mm OD x 5340 mm L

- bulk, 1/4" (6 mm) x 174" (4420 mm) long

1шт.
