Запчасти Case W26B (094) - INSTRUMENT PANEL (RIGHT HAND SIDE) (04) - ELECTRICAL SYSTEMS

1

L13270

PANEL - instrument, R.H.

1шт.

2

L13285

TIE BAR - instrument panel

1шт.

3

L13286

ANGLE - mounting, instrument panel

1шт.

4

13-510

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5, Full Thd

2шт.

5

92-5

LOCK WASHER,5/16"

2шт.

6

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

2шт.

7

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

8

L13287

BRACKET - center, panel mounting

1шт.

9

175-405

SCREW,Phil Truss Hd, 1/2" - 20 x 1/2"

- machine, truss head (1/4" - 20 NC x 1/2")

6шт.

10

193-28

LOCK WASHER,Int Tooth, 1/4"

WASHER - lock, internal Shakeproof (1/4")

6шт.

11

L13233

NUT - Tinnerman (1/4" - 20 NC)

2шт.

12

L13271

ELECTRICAL GAUGE

GAUGE - pressure, hydraulic pump inlet

1шт.

13

218-915

HYD CONNECTOR,Sw, 1/8" NPT Fem x 1/8" NPSM Fem

UNION - adaptor, gauge to hose

1шт.

14

217-220

ELBOW UNION

ELBOW - street, reducer

1шт.

15

L40279

HOSE ASSY.

HOSE - gauge to hydraulic pump inlet tube

1шт.

16

L12141

ELECTRICAL GAUGE

GAUGE - air pressure

1шт.

17

217-1

ADAPTER

-, Serial Range: gauge-tee

1шт.

18

L13273

UNION TEE

TEE - special, air pressure gauge

1шт.

19

218-481

ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 1/8" - 27 Male NPTF

- male, 90 degrees

1шт.

20

L12629

HOSE

- air pressure, Serial Range: gauge-valve

1шт.

21

218-491

ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 1/4" - 18 Male NPTF

- male, 90 degrees

1шт.

22

L10372

SWITCH

- warning, brake air pressure

1шт.

23

L13277

WIRE -, Serial Range: buzzer-switch

1шт.

24

L15056

BUZZER

- warning, air pressure

1шт.

25

175-400

SCREW,Sl Truss Hd, 1/4" - 20 x 1/2"

- truss head (1/4" - 20 NC x 1/2")

2шт.

26

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

WASHER, LOCK, 1/4"

2шт.

27

7770

NUT,Hex, 1/4 - 20, Cl 5

1/4"-20, G5

2шт.

28

A31060

ELECTRICAL WIRE

WIRE - ground, buzzer

1шт.

29

A56447

ELECTRICAL GAUGE

GAUGE - pressure, clutch

1шт.

222-5150

FITTING,3/8"-24 x 1/8" NPT, Hi-seal

CONNECTOR ASSEMBLY - flex tube, Includes: Ref. 30 - 32

1шт.

30

NSS

NOT SOLD SEPARAT

BODY - connector

1шт.

31

222-5045

SLEEVE,1/8" Tube

- connector

1шт.

32

222-5058

NUT,3/8"-24

NUT - connector

1шт.

33

L16685

TUBE,0.078" ID x 0.125" OD x 86" L

- clutch pressure gauge to transmission

1шт.

34

A13756

GAUGE

- converter oil temperature (When stock is exhausted, order L51460 gauge for service)

1шт.

34

L51460

ELECTRICAL GAUGE

GAUGE - converter oil temperature

1шт.

35

A18311

ELECTRICAL WIRE

WIRE - ground, converter temperature gauge to panel (Used with A13756 gauge only)

1шт.

36

A19349

RESISTOR

- gauge, 75 ohm

1шт.

37

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

WASHER, LOCK, #10

1шт.

38

129-37

NUT,#10-32

1шт.

39

L13275

LAMP

LIGHT - instrument panel (Parts list figure 92)

2шт.

40

A8210

CONNECTOR, ELEC

CONNECTOR - panel, Serial Range: lights-harness

1шт.

41

L40306

HARNESS - wiring, instrument panel (R.H.)

1шт.
