Запчасти Case W26B (466) - DECALS LATE PRODUCTION (09) - CHASSIS

Схема запчастей Case W26B - (466) - DECALS LATE PRODUCTION (09) - CHASSIS
5
15
16
7
1
3
8a
10
9
4
16
17
8
14a
6
12
2
15a
13
7a
10
19
14

Артикул

Название

Примечание

Количество

1

321-1077

DECAL

- air drain (air reservoirs, front frame)

2шт.

2

321-1075

DECAL

- bucket control pattern (Upper R.H. rear front frame)

1шт.

3

321-1734

DECAL

- transmission (Outside of shift indicator cover at steering column)

1шт.

4

321-3206

DECAL

- safety link (R.H. rear frame at link bracket)

1шт.

5

321-3094

DECAL

- Hood, R.H.

1шт.

6

321-3093

DECAL

- hood, L.H.

1шт.

7

321-3168

DECAL

- "Case" (Rear)

1шт.

7a

321-3098

DECAL

- "Case" (front)

1шт.

8

321-3167

DECAL

- W26B (L36156 kit only)

1шт.

8a

321-3210

DECAL - W26LF (L36157 kit only)

1шт.

9

321-1619

DECAL

- transmission oil level (L.H. rear frame at filler pipe)

1шт.

10

321-3205

DECAL

- warning (Lower front of rear frame)

2шт.

11

321-3207

DECAL

- hydraulic tank daily check (On tank cover)

1шт.

12

321-3207

DECAL

- bucket positioning indicator, at bellcrank

1шт.

13

A17710

DECAL

- clam opening, L.H. side of bucket blade

1шт.

14

321-2065

DECAL

- engine operating

1шт.

14a

654-3122

DECAL - 8" tread

2шт.

15

321-1733

DECAL - transmission range (Inside of shift indicator cover)

1шт.

15a

321-3061

DECAL

- warning, radiator pressure cap

1шт.

16

321-1639

DECAL - start position (Instrument panel)

1шт.

17

321-3284

DECAL

- shifting warning

1шт.

18

321-3034

DECAL - emergency steering

1шт.

19

321-3596

DECAL

- caution, fan

2шт.

L36156

DECAL

KIT - decal, W26B (All decals except 8A, 16 and 18)

1шт.

L36157

DECAL

KIT - decal, W26LF (All decals except 8, 16 and 18)

1шт.

Выбрано товаров: 25
