Запчасти Case W26B (464) - DECALS EARLY PRODUCTION (09) - CHASSIS

1

321-1077

DECAL

- air drain (Air reservoirs, front frame)

2шт.

2

321-1075

DECAL

- bucket control pattern (Upper R.H. rear front frame)

1шт.

3

321-1734

DECAL

- transmission (Outside of shift indicator cover at steering column)

1шт.

4

321-3596

DECAL

- caution, fan

2шт.

5

321-3206

DECAL

- safety link (R.H. rear frame at link bracket)

1шт.

6

321-1143

DECAL

- "CASE" over "W26B" (Hood side panels) Reflective (When stock is exhausted, order 321-1574 non-reflective decal for service)

2шт.

6

321-1574

DECAL

- "CASE" over "W26B" (Hood side panels) non-reflective

2шт.

7

321-1921

DECAL

- "W26B" under "CASE" (Hood side panels) L45507 kit only

2шт.

7

321-1922

DECAL - "W26LF" under "CASE" (Hood side panels) L35239 kit only (Not shown)

2шт.

8

321-1442

DECAL

- "CASE" (Below grille between rear lights) Reflective (When stock is exhausted, order 321-2427 Non-reflective decal for service)

1шт.

8

321-2427

EMBLEM

DECAL - "CASE" (Below grille between rear lights) Non-reflective

1шт.

9

321-1445

DECAL

- "CASE" (Front frame above access cover) Reflective (When stock is exhausted, order 321-2429 non-reflective decal for service)

1шт.

9

321-2429

EMBLEM

DECAL - "CASE" (Front frame above access cover) Non-reflective

1шт.

10

321-1619

DECAL

- transmission oil level (L.H. rear frame at filler pipe)

1шт.

11

321-3205

DECAL

- warning (Lower front of rear frame)

2шт.

12

321-3207

DECAL

- hydraulic tank daily check (On tank cover)

1шт.

13

321-1223

DECAL

- bucket positioning indicator, at bellcrank

1шт.

14

A17710

DECAL

- clam opening, L.H. side of bucket blade

1шт.

14a

321-1981

DECAL

- attention (when stock is exhausted, order 321-2605 decal for service)

1шт.

14b

321-2605

DECAL

- engine operating

1шт.

14c

321-3061

DECAL

- warning, radiator pressure cap

1шт.

15

321-1733

DECAL - transmission range (Inside of shift indicator cover)

1шт.

16

321-1663

DECAL

- bucket control pattern (3 spool vavle) Upper R.H. rear front frame (Models with Drott bucket)

1шт.

17

321-1639

DECAL - start position (Instrument panel)

1шт.

L45507

DECAL

KIT - decal, W26B (All decals except 15, 16, 17 and 321-1922)

1шт.

L35239

DECAL

KIT - decal, W26LF (All decals except 15, 16, 17 and 321-1931)

1шт.
