Запчасти Case W26B (342) - NOISE REDUCTION PARTS (09) - CHASSIS

L57540

KIT - noise reduction, Includes: Ref. 1 - 9

1шт.

1

L57532

PADDING - compartment (R.H. side)

1шт.

2

L57530

PADDING - compartment (L.H. side)

1шт.

3

L57419

PADDING - compartment door

1шт.

4

L57489

PADDING - compartment rear

1шт.

5

L58409

PADDING - compartment (R.H. front)

1шт.

6

L57495

PADDING - compartment (L.H. front)

1шт.

7

L57546

HEADLINER - cab

1шт.

8

L57531

FLOOR MAT - cab

1шт.

9

L57529

MAT - platform

1шт.

10

L57711

PLATE - platform mat retaining

1шт.

11

13-520

BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5

HHCS - 5/16" - 18 NC x 1-1/4"

4шт.

12

92-5

LOCK WASHER,5/16"

4шт.

13

9635082

NUT,5/16" - 18, Gr 5

- hex. (5/16" - 18 NC)

4шт.

14

L57544

BRACKET - compartment

1шт.

15

187-847

SCREW

- self-tapping (1/4" - 20 NC x 3/4")

4шт.

16

195-18

WASHER,1/4"

- standard wrot () 1/4"

4шт.

17

L54813

BRACKET - floormat

1шт.

18

187-847

SCREW

- self-tapping (1/4" - 20 NC x 3/4")

2шт.

19

195-18

WASHER,1/4"

- standard wrot () 1/4"

2шт.
