Запчасти Case W26B (016) - INTAKE MANIFOLD, (504 BDT) DIESLE ENGINE (02) - ENGINE

1

A62845

MANIFOLD

ASSY. - (aluminum), Includes: Ref. 2

1шт.

2

41-1042

PLUG,Cup, 2 5/8"

- (2-5/8" cup type)

1шт.

3

A58660

MANIFOLD

ASSY. - (Cast Iron), Includes: Ref. 4 and 5

1шт.

4

41-1042

PLUG,Cup, 2 5/8"

- (2-5/8" cup type)

1шт.

5

41-1020

PLUG,Cup, 1 1/4"

- (1-1/4" cup type)

2шт.

6

221-1840

PLUG

- intake manifold (1/8" P.T. sckt. hd.)

1шт.

7

A58662

MANIFOLD GASKET

- intake, Serial Range: manifold-head

6шт.

8

A59077

STUD

- intake manifold (3/8" N.C. x 1-3/4")

12шт.

9

92-6

LOCK WASHER,3/8"

12шт.

10

25-106

NUT,3/8"-16, G5

- intake manifold stud (3/8" N.C. hex.)

12шт.

11

A66333

HEATER

- intake manifold (Replaces A34278)

1шт.

12

129-503

NUT,1/4"-20, Brass

1шт.

13

A20916

MANIFOLD GASKET

GASKET -, Serial Range: heater-manifold

1шт.

18

A65917

MANIFOLD

- front & rear (w/heavy stud boss), exhaust, 1st used engine ser. no. 2529905, Start Serial: 2529905

2шт.

19

A76322

MANIFOLD

- center (w/heavy stud boss), exhaust, 1st used engine ser. no. 2529905, Start Serial: 2529905

1шт.

20

A58895

GASKET

- exhaust manifold to head, 1st used engine ser. no. 2529905, Start Serial: 2529905

6шт.

21

A35175

STUD

- manifold (3/8" N.C. x 2-7/16"), exhaust, 1st engine used ser. no. 2529905, Start Serial: 2529905

12шт.

22

92-6

LOCK WASHER,3/8"

exhaust manifold, 1st engine used ser. no. 2529905 3/8", Start Serial: 2529905

12шт.

23

131-903

NUT,3/8"-16

NUT - 3/8" N.C. hex., seez-pruf., exhaust manifold, 1st engine used ser. no. 2529905, Start Serial: 2529905

12шт.

28

A58907

EXHAUST MANIFOLD

MANIFOLD - front & rear (w/thin stud boss) (Order 1-A65917 end section & 4-A35175 studs), used prior to eng. ser. no. 2529905, Start Serial: 2529905

2шт.

29

A58906

TUBE

MANIFOLD - center (w/thin stud boss) (Order 1-A76322 center section & 4-A35175 studs), used prior to eng. ser. no. 2529905, Start Serial: 2529905

1шт.

30

A58895

GASKET

- exhaust manifold to head, used prior to eng. ser. no. 2529905, Start Serial: 2529905

6шт.

31

A59077

STUD

- exhaust manifold (3/8" N.C. x 1-3/4"), used prior to eng. ser. no. 2529905, Start Serial: 2529905

12шт.

32

92-6

LOCK WASHER,3/8"

exhaust manifold, used prior to eng. ser. no. 2529905 3/8", Start Serial: 2529905

12шт.

33

131-903

NUT,3/8"-16

NUT - exhaust manifold stud (3/8" N.C. Seez-Pruf), used prior to eng. ser. no. 2529905, Start Serial: 2529905

12шт.
