Запчасти Case W24B (146) - STEERING PUMP AND RELATED PARTS (05) - STEERING

1

L18519

CAP

- steering wheel

1шт.

2

L47502

WHEEL

- steering

1шт.

3

REF

INSTRUCTION

PUMP - steering (See Figure 148 - 149C for proper pump)

1шт.

4

L52712

PLATE - steering pump mounting (Used with Char - Lynn manufacture d steering gear, see figures 148 - 149C)

1шт.

4a

L58235

PLATE - steering pump mounting (Used with Ross manufactured steer ing gear, see figures 148 - 149C)

1шт.

5

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

2шт.

6

92-6

LOCK WASHER,3/8"

2шт.

7

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

6шт.

8

95-6

WASHER,3/8"

- standard wrot () 3/8"

2шт.

9

92-6

LOCK WASHER,3/8"

6шт.

9a

25-106

NUT,3/8"-16, G5

- hex. (3/8" - 16 NC)

2шт.

10

L50073

BEARING CARRIER

BEARING ASSEMBLY - steering column (Used with Char - Lynn manufac tured steering gear, see figures 148 - 149C)

1шт.

10a

L45471

BEARING

ASSEMBLY - steering column (Used with Ross manufactured steering gear, see figures 148 - 149C)

1шт.

11

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

2шт.

12

195-25

WASHER,3/8"

- plain () 3/8"

2шт.

13

92-6

LOCK WASHER,3/8"

2шт.

14

25-106

NUT,3/8"-16, G5

- hex. (3/8" - 16 NC)

2шт.
