Запчасти Case W24 (130) - BRAKE SYSTEM, CLUTCH CUTOUT CONTROL, AND PRESSURE PROTECTION VALVES L14818 CLUTCH CUTOUT VALVE, (07) - BRAKES
№
Артикул
Название
Примечание
Количество
1
L14818
VALVE
- clutch cutout control, Includes: Ref. 2 - 12
1шт.
2
L32338
BOOT
- valve, clutch cutout control
1шт.
3
129-574
NUT - hex. (3/4" - 16 NF)
2шт.
4
L32337
ADAPTER - valve, clutch cutout control
1шт.
5
L32336
O-RING,0.07" Thk x 0.364" ID, -12, Cl 5, 75 Duro
SEAL - "O" ring, plunger (Large)
1шт.
6
L32335
PLUNGER
- valve, clutch cutout control
1шт.
7
NSS
NOT SOLD SEPARAT
BODY - valve, clutch cutout control
1шт.
8
L31798
O-RING,1/8" ID x 1/4" OD x 1/16"
SEAL - "O" ring, stem (Small)
1шт.
9
L32332
STEM
- valve, clutch cutout control
1шт.
10
L31354
VALVE
POPPET - air intake
1шт.
11
L32333
VALVE SPRING
SPRING - valve, clutch cutout control
1шт.
12
L32334
ADAPTER - air intake
1шт.
13
L13530
VALVE
ASSEMBLY - pressure protection, L13530, Includes: Ref. 14 - 25
1шт.
14
NSS
NOT SOLD SEPARAT
BODY - valve, L13530 pressure protection
1шт.
15
L31802
VALVE
- inlet, L13530 pressure protection
1шт.
16
NSS
NOT SOLD SEPARAT
RETAINER - valve, L13530 pressure protection
1шт.
17
L31800
SPRING
- inlet valve, L13530 pressure protection
1шт.
18
NSS
NOT SOLD SEPARAT
STEM - valve, L13530 pressure protection
1шт.
19
131-414
LOCK NUT,PAL, 7/8"-14
PALNUT - hex., lock (7/8" - 14 NF), L13530 pressure protection valve
1шт.
20
NSS
NOT SOLD SEPARAT
PISTON - valve, L13530 pressure protection valve
1шт.
21
L31797
O-RING,1/2" ID x 11/16" OD x 3/32"
SEAL - "O" ring, piston, L13530 pressure protection valve
1шт.
22
NSS
NOT SOLD SEPARAT
PLUG - valve, L13530 pressure protection
1шт.
23
L31798
O-RING,1/8" ID x 1/4" OD x 1/16"
SEAL - "O" ring, plug, L13530 pressure protection valve
1шт.
24
NSS
NOT SOLD SEPARAT
SPRING - pressure regulating, L13530 pressure protection valve
1шт.
25
L31805
END CAP - adjusting (When stock is exhausted, order L32729 end cap for service), L13530 pressure protection
1шт.
25
L32729
END CAP - adjusting (When stock is exhausted, order L32931 end cap for service), L13530 pressure protection
1шт.
25
L32931
END CAP - adjusting (When stock is exhausted, order L33316 cap for service), L13530 pressure protection
1шт.
25
L33316
CAP
END CAP - adjusting, L13530 pressure protection
1шт.
Выбрано товаров: 28
