Запчасти Case W20 (152) - L58924 DIFFERENTIAL ASSEMBLY ROCKWELL STANDARD F22-3200-U-1113/5.29 (06) - POWER TRAIN

L33665

YOKE

UNIVERSAL JOINT YOKE ASSEMBLY - drive shaft, Includes Ref: 1, 2

1шт.

1

NSS

NOT SOLD SEPARAT

YOKE - drive shaft

1шт.

2

L33666

DEFLECTOR

SLINGER - oil

1шт.

L58924

CARRIER

DIFFERENTIAL ASSY, Includes Ref: 3-42, Orig. equip. in L59406 axle (Rockwell Stdrd PR-80-HX-22) Svc replacement for L33631 differential (Rockwell Stdrd A16-3200-E-785/5.2/7-1 and L35936 differential

1шт.

3

A13124

WASHER

special

1шт.

4

RESERVED

1шт.

5

RESERVED

1шт.

6

L33675

SPACER

WASHER - thrust, yoke

1шт.

7

13-724

BOLT,Hex, 7/16" - 14 x 1-1/2", Gr 5

8шт.

L33672

COVER

ASSEMBLY - pinion shaft, Includes Ref: 8, 9

1шт.

8

NSS

NOT SOLD SEPARAT

COVER - pinion shaft

1шт.

9

L33673

OIL SEAL

oil pinion shaft

1шт.

10

L33674

GASKET

, Serial Range: cover-cage

1шт.

L33667

CAGE

ASSEMBLY - pinion shaft bearing, Includes Ref: 11, 12

1шт.

11

NSS

NOT SOLD SEPARAT

CAGE - bearing

1шт.

12

L33668

BEARING CUP

bearing pinion shaft

2шт.

13

L35937

BEARING

CONE - pinion shaft

2шт.

14

L33679

SPARE PART bearing, 165" thick

1шт.

14

L33680

SPACER

bearing, 166" thick

1шт.

14

L33681

SPARE PART bearing, 167" thick

1шт.

14

L33682

SPARE PART bearing, 168" thick

1шт.

14

L33683

SPARE PART bearing, 169" thick

1шт.

14

L33684

SPACER

bearing, 170" thick

1шт.

14

L33685

SPACER

bearing, 176" thick

1шт.

14

L33886

SPARE PART SPACER - bearing, 183" thick

1шт.

14

L33687

SPACER

bearing, 188" thick

1шт.

14

L33688

SPARE PART bearing, 194" thick

1шт.

14

L33689

SPARE PART bearing, 200" thick

1шт.

L36102

PACKAGE, REPAIR

bevel gear repair, Includes Ref: 15-22

1шт.

15

NSS

NOT SOLD SEPARAT

GEAR - ring

1шт.

16

NSS

NOT SOLD SEPARAT

GEAR - pinion

1шт.

17

A18182

BALL BEARING,27.75mm ID x 62mm OD x 18mm W

spigot

1шт.

18

A18199

SNAP RING,#106, Ext

Ring, Snap, , bearing #106, Ext

1шт.

19

L35919

BOLT

special, ring, Serial Range: gear-differential

12шт.

20

D47366

WASHER

special

12шт.

21

131-1138

LOCK NUT,1/2"-13, GC

hex self-locking (1/2")

12шт.

22

L35091

NUT

yoke retaining

1шт.

23

L36104

SHIM

bearing cage, .003"

1шт.

23

L36105

SHIM

bearing cage, .005""

1шт.

23

L36106

DISC

SHIM - bearing cage, 010"

1шт.

L35938

CARRIER

AND CAP ASSEMBLY - differential, Includes Ref; 24-29

1шт.

24

221-835

PLUG

pipe, square head (3/4" NPT)

1шт.

25

NSS

NOT SOLD SEPARAT

CARRIER - differential

1шт.

26

NSS

NOT SOLD SEPARAT

CAP - differential bearing

2шт.

27

A15443

DOWEL

cap

1шт.

28

26-1052

BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 8

5/8" - 11 NC x 3-1/4" (Grade 8)

4шт.

29

L30737

WASHER

special

4шт.

L36096

SPARE PART CASE AND GEAR ASSEMBLY - differential, Includes Ref: 30-38

1шт.

L36097

SPLIT PIN/SAFETY PIN

BODY ASSEMBLY - case and gear, Includes Ref: 30-32

1шт.

30

NSS

NOT SOLD SEPARAT

CASE - differential plain half

1шт.

31

NSS

NOT SOLD SEPARAT

CASE - differential flange half

1шт.

32

L36101

SPARE PART special short

1шт.

33

L34062

BOLT

special, case halves

8шт.

34

F9740

WASHER,60.68mm ID x 90.42mm OD x 1.58mm Thk

thrust side gear

2шт.

35

D66304

GEAR

differential side

2шт.

36

L36098

U-JOINT SPIDER

differential

1шт.

37

L36099

PINION

GEAR - differential

1шт.

38

L36100

WASHER

thrust

4шт.

39

A18173

ROLLER BEARING

CONE - differential

2шт.

40

L35931

BEARING CUP

bearing differential

2шт.

41

A18194

RING

bearing adjusting

1шт.

42

A18196

HARDWARE

PIN - cotter special

1шт.
