Запчасти Case W20 (230) - HYDRAULIC TANK AND RELATED PARTS BEFORE TRACTOR S.N. 9107854 AND FUEL PUMP (03) - FUEL SYSTEM

1

13-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5, Full Thd

5шт.

2

92-10

LOCK WASHER,5/8"

5шт.

3

25-1010

NUT,5/8"-11, G5

5шт.

4

L48332

SPARE PART hydraulic tank

1шт.

5

L16680

GAUGE

oil level

1шт.

6

218-5012

O-RING,0.118" Thk x 1.720" ID, -924, Cl 6, 90 Duro

1шт.

7

25-106

NUT,3/8"-16, G5

hex (3/8" - 16 NC)

6шт.

8

92-6

LOCK WASHER,3/8"

6шт.

9

L48078

SPARE PART hydraulic tank

1шт.

10

L16974

SEAL

cover, hydraulic tank

1шт.

11

L13023

STUD

cover (3/8" - 16 NC)

6шт.

12

L12682

LOCK VALVE

relief, filter

3шт.

51200336

FILTER, ELEMENT

ELEMENT, FILTER KIT - hydraulic tank, Includes Ref: 13, 14

3шт.

13

NSS

NOT SOLD SEPARAT

ELEMENT - hydraulic tank

1шт.

14

34458

element (Not required in this application)

1шт.

15

L47429

TANK - hydraulic

1шт.

16

221-677

DRAIN PLUG,Sq Hd, 3/4" NPT

magnetic drain

2шт.

17

L14422

STUD - hvdraulictank

4шт.

L14569

PUMP

fuel transfer, Includes Ref: 18-28

1шт.

L52634

PUMP

fuel transfer, Includes Ref: 18-28

1шт.

18

A40312

COVER

fuel pump

1шт.

19

A40315

GASKET

COVER, fuel pump

1шт.

20

A40311

MAGNET

plunger, fuel pump

1шт.

21

A40314

FILTER CARTRIDGE

FILTER - fuel (L14569 pump)

1шт.

21

L33210

FILTER SCREEN

filtering (L52634 pump), fuel

1шт.

22

A40316

RETAINER

SEAL, Oring, fuel pump

1шт.

23

A40317

WASHER

special, retainer, fuel pump

1шт.

24

A40318

O-RING,0.429" ID x 0.106"

VALVE, fuel pump

1шт.

25

A40313

CUP

VALVE, fuel pump

1шт.

26

L32394

VALVE SPRING

plunger (When stock is exhausted order L35316 spring for service), fuel pump

1шт.

26

L35316

SPRING

plunger, fuel pump

1шт.

27

A40310

PLUNGER

fuel pump

1шт.

28

NSS

NOT SOLD SEPARAT

BODY - pump, fuel transfer

1шт.

29

L11779

TUBE,0.187" ID x 0.187" OD x 1" L

SLEEVE - insulation, fuel pump

1шт.

30

L11778

CONNECTOR, ELEC

CONNECTOR male, bullet, fuel pump

1шт.
