Запчасти Case W14B (7-30) - BRAKE SYSTEM, FLUID RESERVOIRS TO BRAKE ACTUATORS, *UNITS (07) - BRAKES

1

L114928

RESERVOIR ASSY.

RESERVOIR - brake fluid, parts list Figure 7-54

2шт.

2

L127200

BRACKET

- reservoir support

1шт.

3

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

- hex, 3/8 NC x 1 inch

3шт.

4

413-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5

- hex, 3/8 NC x 1-1/4 inch

2шт.

5

495-21044

WASHER,3/8"

(flat, 7/16 x 1 x 5/64 inch) 3/8"

8шт.

6

492-11038

LOCK WASHER,3/8"

5шт.

7

425-106

NUT,3/8"-16, Cl 5

5шт.

8

217-1080

HYD CONNECTOR,1/4" - 18 NPT x 1/4" - 18 NPT

CONNECTOR, (NIPPLE, PIPE) x 1-7/16" lg. 1/4"-18 NPTF

1шт.

9

L108742

HOSE

- 6 mm x 265 mm long, brake fluid, reservoir to brake actuator

1шт.

10

214-274

HOSE CLAMP,#04, 0.25" - 0.62", Type F Worm

2шт.

11

217-294

FITTING,90 Degree Elbow, 1/4" Hose Barb x 1/4" Male NPTF

ELBOW - 90 degree, 1/4 inch barb end x PT

2шт.

12

L117713

MASTER CYLINDER

BRAKE ACTUATOR ASSEMBLY - parts list Figure 7-38

1шт.

13

L113007

CYLINDER

BRAKE ACTUATOR ASSEMBLY - parts list Figure 7-36

1шт.

14

413-628

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

- hex, 3/8 NC x 1-3/4 inch

2шт.

15

495-21044

WASHER,3/8"

(flat, 7/16 x 1 x 5/64 inch) 3/8"

4шт.

16

492-11038

LOCK WASHER,3/8"

2шт.

17

425-106

NUT,3/8"-16, Cl 5

2шт.
