Артикул
Название
Примечание
Количество
1
L56064
KNOB
- control lever
2шт.
2
L59087
LEVER
- lift
1шт.
3
L59089
LEVER
- bucket
1шт.
4
L59090
DIPPER
BELLCRANK - lever, upper
2шт.
5
86637932
JAM NUT,Jam, 5/8"-18, G5
- hex, 5/8"-18 NF
2шт.
5a
193-34
LOCK WASHER,Int Tooth, 5/8"
WASHER, LOCK, Int Tooth, 5/8"
2шт.
6
219-55
LUBE NIPPLE,90 Degree Elbow, 1/8" - 27 NPTF
NIPPLE, LUBE, 90º, 1/8" NPT x .84" lg
2шт.
7
138-223
LOCK PIN,1/8" x 2", Slotted
Pin, , used with L76950 console only, Ref. 22 1/8" x 2", Slotted
4шт.
8
L102849
SHAFT,19.05mm OD x 195.58mm L
- lever pivot
2шт.
9
L55379
BUSHING,19.05mm ID x 26.9mm OD x 54mm L
SPACER - pivot shaft
2шт.
10
132-48
COTTER PIN,1/8" x 1"
Pin, Split (Cotter), 1/8" x 1"
6шт.
11
141-6
CLEVIS PIN,1/2" x 1.360"
- 1/2"
6шт.
12
L59968
LINK
ROD - control
2шт.
13
L59927
SEAL
- control rods, cab models
2шт.
14
L76911
PLATE
- seal retaining, cab models
1шт.
15
L70085
SEAL
- plate, cab models
1шт.
16
163-12
SCREW,Hex, #10 - 24 x 3/4"
MACHINE SCREW - hex heads, No. 10 - 32 NF x 3/4"
4шт.
17
95-3
WASHER,#12
- flat, No. 10
4шт.
18
92-3
LOCK WASHER,#10
WASHER, LOCK, #10
4шт.
19
129-7
NUT,Hex, #10 - 24
- hex, No. 10 - 32 NF
4шт.
20
L51047
DIPPER
BELLCRANK - spool actuating, lower
2шт.
21
219-1
LUBE NIPPLE,1/8" - 27 NPTF
GREASE FITTING - straight, 1/8" NPT
2шт.
22
L76950
SUPPORT
CONSOLE - control, not available, order L106722 console
1шт.
22a
L106722
SUPPORT
CONSOLE - control
1шт.
23
13-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd
4шт.
23a
95-6
WASHER,3/8"
- flat, 3/8"
8шт.
24
92-6
LOCK WASHER,3/8"
4шт.
25
25-106
NUT,3/8"-16, G5
- hex, 3/8"-16 NC
4шт.
26
25-158
JAM NUT,Jam, 1/2"-20, G5
JAM NUT - hex, 1/2"-20 NF
6шт.
27
213-6
ADJUSTABLE CLEVIS,1/2"-20 x 3"
CLEVIS - connecting link
4шт.
28
L73826
ROD
- control, bucket
1шт.
29
L73890
ROD
- control, lift
1шт.
30
13-872
BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5
3шт.
31
L100006
BRACKET
- valve mounting
1шт.
32
92-8
LOCK WASHER,1/2"
3шт.
33
25-108
NUT,1/2"-13, G5
- hex, 1/2"-13 NC
3шт.
34
REF
INSTRUCTION
VALVE - loader, Hydreco, parts list figure 514
1шт.
35
13-840
BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5
- hex head, 1/2"-13 NC x 2-1/2"
3шт.
36
D64050
WASHER
- special
3шт.
36a
92-8
LOCK WASHER,1/2"
3шт.
37
25-108
NUT,1/2"-13, G5
- hex, 1/2"-13 NC
3шт.
38
L100609
CLEVIS
, Serial Range: --valve
2шт.
39
141-61
CLEVIS PIN,5/16" x 1 3/16"
- 5/16"
2шт.
40
132-26
COTTER PIN
Pin, Split (Cotter), 3/32" x 3/4"
2шт.
41
L59992
COVER
- ROPS models
1шт.
42
182-131
SCREW,Sl Pan Hd, #10 - 24 x 1 1/4"
- round head, slotted, No. 10 - 24 NC x 1-1/4"
6шт.
43
95-3
WASHER,#12
- flat, No. 10
6шт.
44
92-3
LOCK WASHER,#10
WASHER, LOCK, #10
6шт.
45
129-7
NUT,Hex, #10 - 24
- hex, No. 10 - 24 NC
6шт.
Выбрано товаров: 49
