Запчасти Case W14 (142) - STEERING CYLINDER HYDRAULICS (05) - STEERING

1

REF

INSTRUCTION

PUMP ASSEMBLY - steering, parts list Figure 138

1шт.

2

218-5106

90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

Adjustable, Includes Ref. 3

1шт.

3

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

Seal

1шт.

4

L50016

HOSE

Steering gear to elbow at RH steering cylinder, 35" long

1шт.

5

L50015

HOSE

Steering gear to elbow at LH steering cylinder, 30" long

1шт.

6

218-5006

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

Seal

1шт.

7

218-5220

TEE,37 Degree, 7/8"-14 x 7/8"-14, Fem Sw Run

Adjustable, hydraulic

2шт.

8

L51198

HOSE,0.50" ID x 28.00", SAE 100R2 Type A

Crossover, cylinder, 28" long

2шт.

9

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

Seal

2шт.

10

218-5107

90 ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB

Adjustable, Incl. Ref. 11

2шт.

11

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

Seal

1шт.

12

REF

INSTRUCTION

CYLINDER - steering, see Figure 144 and 145A for cylinders

2шт.

13

13-828

BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5

HHCS - 1/2" - 13 NC x 1-5/8"

2шт.

14

131-10

NUT,1/2"-13, GB

2шт.

15

L50753

PIN,31.75mm OD x 93.98mm L

Cylinder mounting

2шт.

16

R17756

ROD,12.7mm OD x 109.54mm L

PIN - cylinder pin retaining

2шт.

17

L72501

PIN

Cylinder mounting

2шт.

18

L50969

WASHER

Special

4шт.

19

L51051

WASHER,26.92mm ID x 63.5mm OD x 12.7mm Thk

Special

2шт.

20

131-19

LOCK NUT,1"-14, GB

2шт.

REF. 20 - IS A 1" x 14 FINE THREAD.

1шт.
