Запчасти Case W14 (165E) - L57831 OPERATOR CAB (09) - CHASSIS

L57831

CAB - operators, (Machinery Item) Sims No. 1000-347, Includes Ref. 1 - 35

1шт.

1

NSS

NOT SOLD SEPARAT

FRAME - cab

1шт.

2

REF

INSTRUCTION

MOTOR - wiper, see 265K

1шт.

REF. 2 SEE FIGURE 165C

1шт.

3

L35743

SWITCH

L35259 motor, bullet terminals

1шт.

3

F63532

SWITCH

F93455 motor, spade terminals

1шт.

4

L35260

ARM

Windshield wiper, 20"

1шт.

5

L35261

BLADE

Windshield wiper, 20"

1шт.

6

L35753

ADAPTER

Double arm wiper

1шт.

7

NSS

NOT SOLD SEPARAT

STRIKER - lower, RH front (replaces D70406)

1шт.

8

NSS

NOT SOLD SEPARAT

STRIKER - lower, LH front (replaces D66500)

1шт.

9

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3шт.

10

195-104

WASHER,3/8"

3шт.

11

192-21

LOCK WASHER,3/8"

3шт.

12

129-103

NUT,Hex, 3/8" - 16, Gr 5

3шт.

13

D66493

DOOR ASSY.

FRAME - upper, RH, Includes Ref. 15 and 16

1шт.

14

D66492

DOOR ASSY.

SPARE PART FRAME - upper, LH, Includes Ref. 15 and 16

1шт.

15

RESERVED

1шт.

16

RESERVED

1шт.

17

L35803

SPARE PART Roof, RH, and LH side

2шт.

18

L35806

SPARE PART Roof, middle

1шт.

19

D66495

DOOR ASSY.

Lower, RH

1шт.

20

D66494

DOOR ASSY.

SPARE PART Lower, LH

1шт.

21

L35738

LATCH

Door, inside, LH

1шт.

22

L35737

LATCH

Door, inside, RH

1шт.

23

187-988

SELF-TAP SCREW,0.19"-16 x 3/4"

8шт.

24

D71372

HANDLE

ASSEMBLY - outside, with keys, Includes Ref. 25

2шт.

25

REF

INSTRUCTION

KEY - order from Sims Co. per number stamped on key and handle

2шт.

26

D66497

SPARE PART Hinge mounting, RH

1шт.

27

D66496

SPARE PART Hinge mounting, LH

1шт.

28

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

6шт.

29

192-21

LOCK WASHER,3/8"

6шт.

30

195-104

WASHER,3/8"

6шт.

31

L35747

LATCH

Door hold back

2шт.

32

L35748

SPRING

Door hold back

2шт.

33

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

34

131-52

NUT,3/8"-16, GC

2шт.

35

205-28

SPARE PART PLUG - rear window wiper hole

1шт.

36

D70582

SPARE PART ASSEMBLY

1шт.

37

182-240

SCREW,Sl Pan Hd, 5/16" - 18 x 1/2"

8шт.

38

RESERVED

1шт.

39

RESERVED

1шт.

40

RESERVED

1шт.

41

RESERVED

1шт.

42

L35798

RUBBER

Door, bottom, 50 ft. roll

1шт.

43

L35799

RUBBER

SPARE PART Self adhesive, door gasket, 50 ft. roll. 3/8" x 5/8"

1шт.

44

L35732

STRIP

WEATHER, MATERIAL, 50 ft. roll

1шт.

45

L35759

SPARE PART MATERIAL - 50 ft. roll

1шт.

46

L35801

FOAM

RUBBER MOUNTING - 50 ft. roll

1шт.
