Запчасти Case W11B (4-066) - ELECTRICAL SYSTEM, OPTIONAL AUTOMATIC AUXILIARY STEERING (04) - ELECTRICAL SYSTEMS

1

L78437

MOTOR

ASSEMBLY - auxiliary steering, parts list Figure 5-16

1шт.

2

413-624

BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5

- hex, 3/8 NC x 1-1/2 inch

4шт.

3

193-53

LOCK WASHER,Ext Tooth, 3/8"

WASHER, LOCK, Ext Tooth, 3/8"

8шт.

4

425-106

NUT,3/8"-16, Cl 5

4шт.

5

L126510

CABLE

- starter to solenoid and solenoid to auxiliary steering motor

2шт.

6

L109874

SOLENOID

RELAY - auxiliary steering motor

1шт.

7

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

- hex, 1/4 NC x 3/4 inch

4шт.

8

193-44

LOCK WASHER,Ext-Int Tooth, 1/4"

WASHER - internal-external tooth lock, 1/4 inch

6шт.

9

425-104

NUT,1/4"-20, Cl 5

- hex, 1/4 inch NC

4шт.

10

L126519

HARNESS

- electrical, auxiliary steering controls

1шт.

11

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

1шт.

12

L126893

HARNESS

- auxiliary steering control harness to pressure switch

1шт.

13

L126826

IGNITION SWITCH

SWITCH - pressure, auxiliary steering

1шт.

14

L118382

LAMP

ASSEMBLY - warning, auxiliary steering, Includes: Ref. 15

1шт.

15

B50213

BULB

- warning lamp, 12 volt, No. 53

1шт.

16

L115398

ELECTRICAL WIRE

WIRE - ground, auxiliary steering warning lamp

1шт.

17

L70804

ELECTRICAL WIRE

WIRE -, Serial Range: solenoid-relay

1шт.

18

L100265

ELECTRICAL WIRE

WIRE - pressure switch to relay, 19 inch (483 mm) long

1шт.

19

L100266

ELECTRICAL WIRE

WIRE - pressure switch to relay, 21 inch (533 mm) long

1шт.

20

L57997

ELECTRICAL WIRE

WIRE -, Serial Range: harness-relay

1шт.

21

L126507

ELECTRICAL WIRE

WIRE -, Serial Range: lamp-relay

1шт.

22

169-77

SCREW - slotted, No. 8 NC x 1 inch

2шт.

23

L108233

MOUNTING CLIP

CLAMP - wire

2шт.

24

495-21019

WASHER,#8

2шт.

25

492-11008

LOCK WASHER,#8

Washer, Lock, #8

2шт.

26

129-6

NUT,#8-32

2шт.

27

151-526

RIVET,Pop, 1/8" x .337"

- pop, 1/8 x 9/32 inch

4шт.

28

L57132

SOCKET

- relay

2шт.

29

L70845

ELECTRICAL WIRE

WIRE - ground

2шт.

30

L101026

RESISTOR

- 47 ohm, 2 watt

1шт.

31

223-126

SLEEVE

- heat shrinkable

3шт.

32

L57998

ELECTRICAL WIRE

WIRE - jumper

1шт.

33

L72299

CAPACITOR

- 2000 mfd, 50 volt

1шт.

34

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

1шт.

35

L70807

BRACKET

- relay

1шт.

36

L112201

RESISTOR

- 50 ohm

1шт.

37

L100226

ELECTRICAL WIRE

WIRE -, Serial Range: socket-socket

1шт.

38

L100227

ELECTRICAL WIRE

WIRE - ground

1шт.

39

S235009

ELECTRICAL WIRE

WIRE -, Serial Range: resistor-socket

2шт.

40

L112202

DIODE

- relay socket

2шт.

41

L126504

RELAY

- auxiliary steering

2шт.
