Артикул
Название
Примечание
Количество
1
REF
INSTRUCTION
CONTROL VALVE - 2 spool, parts list Figure 8-42
1шт.
2
113-429
BOLT,Hex, 1/2" - 13 x 5", Gr 5
3шт.
3
T30946
BUSHING
SPACER - handle, 1/2 inch
3шт.
4
495-21056
WASHER,1/2"
- flat, 9/16 x 1-3/8 x 3/32 inch
2шт.
5
80679
LOCK WASHER,1/20.507 CST ZND
WASHER, LOCK, 1/2"
2шт.
6
425-108
NUT,1/2" - 13, Gr 5
NUT, , Hex 1/2"-13, G5
3шт.
7
193-77
LOCK WASHER,Int Tooth, 1/2"
WASHER, LOCK, Int Tooth, 1/2"
2шт.
8
L107490
COVER
CONSOLE - control valve levers
1шт.
9
113-4
BOLT,Hex, 1/4" - 20 x 1", Gr 5
4-8шт.
10
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
4-8шт.
11
195-102
WASHER,1/4"
- flat, 5/16 x 3/4 x 1/16 inch
4-8шт.
12
131-646
SPRING NUT,Tinn, U, 1/4"-20
- U-type, 1/4" - 20 NC
4-8шт.
13
L107489
COVER
- console, cab models
1шт.
14
A23885
KNOB
- ball, 1/2" - 13 NC
2шт.
15
L78720
LEVER
CONTROL LEVER - bucket, 1/2" diameter, upon depletion of stock order (1) Ref. 33, L78734
1шт.
16
L78716
LEVER
CONTROL LEVER - loader lift, 1/2" diameter, upon depletion of stock order (1) item 34, L78729 control lever
1шт.
17
L77835
BOSS
SPACER - control lever
1шт.
18
L78279
PIN
SHAFT - lever
1шт.
19
A30881
SEALING WASHER,19.45mm ID x 31.35mm OD
WASHER - spacer
1шт.
20
L74982
END
PIN - shaft
1шт.
21
413-520
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
- hex, 5/16 NC x 1-1/4 inch
1шт.
22
192-20
LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND
WASHER, LOCK, 5/16"
1шт.
23
425-105
NUT,5/16"-18, G5
- hex, 5/16 inch NC
1шт.
24
213-4
ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"
CLEVIS - 3/8"
2шт.
25
86585245
SPECIAL NUT,JAM, 5/8" - 18
- hex jam, 3/8 inch NF
2шт.
26
L113578
ROD
-, Serial Range: lever-valve
2шт.
27
141-3
CLEVIS PIN,5/16" x .940"
PIN, CLEVIS, 5/16" x .940"
2шт.
28
141-4
CLEVIS PIN,3/8" x 1.060"
PIN, CLEVIS, 3/8" x 1.060"
2шт.
29
132-320
COTTER PIN,3/32" x 3/4"
PIN, SPLIT (COTTER), 3/32" x 3/4"
4шт.
31
L78085
SEAL
- foam, console, left-hand side, cab models, not shown
1шт.
32
L79122
SEAL
- foam, console, right-hand side, cab models, not shown
1шт.
33
L78734
LEVER
- control, bucket, 1/2" diameter
1шт.
34
L78729
LEVER
- control, loader lift, 1/2" diameter
1шт.
345-44
ADHESIVE
- spray can, 19-1/2 fluid ounces, for attaching foam pads to metal surfaces
1шт.
Выбрано товаров: 35
