Артикул
Название
Примечание
Количество
1
NSS
NOT SOLD SEPARAT
VALVE - intake (Order ref. 40)
6шт.
2
NSS
NOT SOLD SEPARAT
VALVE - exhaust (Order ref. 41)
6шт.
3
NSS
NOT SOLD SEPARAT
INSERT - exhaust valve seat (Order ref. 42)
6шт.
4
NSS
NOT SOLD SEPARAT
GUIDE - valve stem (Order ref. 43)
12шт.
5
A10726
SEAL
SHIELD - oil, intake valve
6шт.
6
A27866
SEAT
- valve spring
12шт.
7
NSS
NOT SOLD SEPARAT
SPRING - valve (Order ref. 44)
12шт.
8
NSS
NOT SOLD SEPARAT
RETAINER - intake valve spring (Order ref. 46)
6шт.
9
NSS
NOT SOLD SEPARAT
ROTO-CAP - exhaust valve (Order ref. 46)
6шт.
10
NSS
NOT SOLD SEPARAT
LOCK - valve spring (Order ref. 47)
24шт.
15
A27881
BRACKET
- rocker shaft
6шт.
16
13-760
BOLT,Hex, 7/16" - 14 x 3-3/4", Gr 5
Bracket Hex, 7/16"-14 x 3 3/4", G5
6шт.
17
A57990
STUD
- bracket & cover (w/N.C. top thread and 3-3/4" bottom thread) (Do not use ref. 18)
6шт.
17
A57458
STUD
- bracket & cover (w/ N.F. top thread and 3-3/4" bottom length) (Order A57990 & 25-107)
6шт.
17
A28124
STUD - bracket & cover (w/N.F. top thread and 3-3/16" bottom length) (Order A57990 & 25-107)
6шт.
18
92-7
LOCK WASHER,7/16"
(Only w/A28124) 7/16"
6шт.
19
A22322
ROCKER
ARM ASSY. - rocker, intake valve (Incl. ref. 22 & 23)
6шт.
20
A22324
ROCKER
ARM ASSY. - rocker, #1, 3 & 5 cyl. exhaust valve (Incl. ref. 22 & 23)
3шт.
21
A22326
ROCKER
ARM ASSY. - rocker, #2, 4 & 6 cyl. exhaust valve (Incl. ref. 22 & 23)
6шт.
22
A21105
ADJUSTMENT SCREW,3/8" - 24 x 1 9/16"
SCREW - adjusting, rocker arm
1шт.
23
25-156
JAM NUT,Jam, 3/8"-24, G5
- jam, adj. screw (3/8" N.F.)
1шт.
24
A57532
SHAFT
- rocker (w/solid plug. see inset A) (1st used eng. SN 2203667)
3шт.
25
SHAFT
- rocker, reamed (See inset B) (Used prior to eng. SN 2203667) (Can use A57532), Includes: Ref. 26
3шт.
26
A26667
PLUG - cup (9/16" O.D.)
2шт.
27
A23671
X
SHAFT - rocker, not reamed (See inset C) (Order A57532 or A21100), Includes: Ref. 28
3шт.
28
A22318
PLUG - cup (17/32" O.D.)
2шт.
29
A27877
SPRING
- rocker shaft
3шт.
30
A27878
WASHER
- rocker shaft end (29/32 x 5/16 x 9/32")
21шт.
31
B18206
SNAP RING,#87, Ext
Ring, Snap, , rocker shaft end #87, Ext
6шт.
32
A27879
TUBE
- oil, rocker shaft
3шт.
33
A27880
O-RING,0.07" Thk x 0.18" ID, -8, Cl 5, 75 Duro
"O" RING - oil tube (3/16 x 5/16 x 1/16")
3шт.
34
A21060
ROD
- push
12шт.
35
NSS
NOT SOLD SEPARAT
LIFTER - push rod (Order ref. 48)
12шт.
40
A33455
VALVE
S - intake (Set of 2)
3шт.
41
A33456
VALVE, ENG EXHAUST,
VALVES - exhaust (Set of 2)
3шт.
42
A33453
KIT
INSERTS - exhaust valve seat (Set of 2)
3шт.
43
A21673
GUIDE
S - valve stem (Set of 2)
6шт.
44
A21694
SPRING
S - valve (Set of 4)
3шт.
45
A21657
LOCK
RETAINERS - intake valve spring (Set of 2 w/locks)
3шт.
46
A57433
COIL
ROTO-CAPS - exhaust valve (Set of 2)
3шт.
47
A40352
LOCK
S - valve spring (Set of 8)
3шт.
48
A21653
KIT
LIFTERS - push rod (Set of 4)
3шт.
Выбрано товаров: 42
