Артикул
Название
Примечание
Количество
2
A18988
TUBE
- master cylinder to clutch control valve
1шт.
3
A18891
LOCK VALVE
VALVE - clutch control (Parts list Figure 122)
1шт.
4
A18977
TUBE - clutch control valve to transmission control valve (Upper)
1шт.
5
13-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
1шт.
6
A12454
CLIP
CLAMP - tube to oil tank
1шт.
7
A12458
SLEEVE
LOOM - tube protector
1шт.
8
195-25
WASHER,3/8"
1шт.
9
92-6
LOCK WASHER,3/8"
1шт.
10
25-106
NUT,3/8"-16, G5
- hex. (3/8" - 16 NC)
1шт.
11
222-1053
HYD CONNECTOR,1/4" Inv Fl
UNION - tube (1/4")
2шт.
12
A18978
TUBE
- clutch control valve to transmission control valve (Front)
1шт.
13
A18979
TUBE
- clutch control valve to transmission control valve (Rear)
1шт.
14
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
2шт.
15
A7922
CLIP
CLAMP -, Serial Range: tube-chassis
2шт.
16
A12458
SLEEVE
LOOM - tube protector
2шт.
17
92-5
LOCK WASHER,5/16"
2шт.
18
9635082
NUT,5/16" - 18, Gr 5
- hex. (5/16" - 18 NC)
2шт.
19
222-1022
ELBOW,90 Degree, 7/16"-24 Inv Fl x 1/8" NPT
- 90 degrees, tube to transmission control valve
1шт.
20
A18980
PIPE
TUBE - master cylinder to Hydrovac cylinder
1шт.
21
A17543
CLAMP - hydraulic pressure tube
1шт.
22
A7922
CLIP
CLAMP - Hydrovac tube to pressure line clamp
1шт.
23
A12458
SLEEVE
LOOM - tube protector
1шт.
24
13-516
BOLT,Hex, 5/16" - 18 x 1", Gr 5
1шт.
25
92-5
LOCK WASHER,5/16"
11шт.
26
9635082
NUT,5/16" - 18, Gr 5
- hex. (5/16" - 18 NC)
1шт.
27
A18554
CYLINDER
- Hydrovac (Parts list Figure 116)
1шт.
28
A18981
TUBE
- Hydrovac cylinder to brake line tee
1шт.
29
A12451
FITTING
TEE - Hydrovac tube to front and rear brake tubes
1шт.
30
13-520
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
HHCS - 5/16" - 18 NC x 1-1/4"
1шт.
31
92-5
LOCK WASHER,5/16"
1шт.
32
9635082
NUT,5/16" - 18, Gr 5
- hex. (5/16" - 18 NC)
1шт.
33
A18983
TUBE
- tee to rear brake hose
1шт.
34
A12453
CLAMP - tube
1шт.
35
A12458
SLEEVE
LOOM - tube protector
1шт.
36
A56478
HYDRAULIC HOSE
HOSE - tube to rear brake tube tee
1шт.
37
A13100
TEE
- rear brake tube
1шт.
38
13-820
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd
1шт.
39
A19490
STRAP
- brake tee support
1шт.
40
92-8
LOCK WASHER,1/2"
1шт.
41
25-148
JAM NUT,Jam, 1/2"-13, G5
- hex, jam (1/2"-13 NC)
1шт.
42
A18986
TUBE
- tee to R.H. rear brake
1шт.
43
A18987
TUBE
- tee to L.H. rear brake
1шт.
44
A12454
CLIP
CLAMP - L.H. rear brake tube
1шт.
45
A12458
SLEEVE
LOOM - tube protector
1шт.
46
A12628
WASHER
LOCK - brake, Serial Range: hose-bracket
2шт.
47
A56478
HYDRAULIC HOSE
HOSE - tube to rear brake cylinder
2шт.
48
A12643
WASHER
- brake, Serial Range: hose-cylinder
2шт.
49
A18982
TUBE - tee to front tubes
1шт.
50
A7922
CLIP
CLAMP - tube
1шт.
51
A12458
SLEEVE
LOOM - tube protector
1шт.
52
A12452
FITTING
TEE - front brake tubes
1шт.
53
A18984
TUBE
- tee to R.H. front brake cylinder
1шт.
54
A18985
TUBE
- tee to L.H. front brake cylinder
1шт.
55
A18990
BRACKET - tube support, R.H.
1шт.
56
A18991
BRACKET - tube, support, L.H.
1шт.
57
13-410
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5, Full Thd
2шт.
58
A7922
CLIP
CLAMP -, Serial Range: tube-bracket
2шт.
59
A12458
SLEEVE
LOOM - tube protector
2шт.
60
92-4
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
2шт.
61
25-104
NUT,1/4"-20, G5
2шт.
62
A12454
CLIP
CLAMP -, Serial Range: tube-axle
1шт.
63
A12458
SLEEVE
LOOM - tube protector
1шт.
Выбрано товаров: 63
