Запчасти Case 600 (224) - RADIATOR SHROUD, HOOD AND SIDE PANELS (05) - UPPERSTRUCTURE CHASSIS

1

L51948

SHROUD - radiator

1шт.

2

13-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5, Full Thd

4шт.

3

T53567

BEARING WASHER,16.66mm ID x 33.33mm OD x 3.43mm Thk

WASHER - special, hardened

8шт.

4

25-1010

NUT,5/8"-11, G5

4шт.

5

13-812

BOLT,Hex, 1/2" - 13 x 3/4", Gr 5

- hex., 1/2" - 13 N.C. x 3/4"

3шт.

6

92-8

LOCK WASHER,1/2"

3шт.

7

95-8

WASHER,1/2"

plain 1/2"

3шт.

8

L51943

SHIELD - battery

1шт.

9

13-840

BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5

- hex., 1/2" - 13 N.C. x 2-1/2"

2шт.

10

L51941

ANGLE - support, radiator guard

1шт.

11

F40733

SPACER - support angle

2шт.

12

95-8

WASHER,1/2"

plain 1/2"

2шт.

13

92-8

LOCK WASHER,1/2"

2шт.

14

25-108

NUT,1/2"-13, G5

- hex., 1/2" - 13 N.C.

2шт.

15

L51947

GRILLE - radiator guard

1шт.

16

L52283

SCREW - cap, hex. socket head, special

2шт.

17

O4215A

WASHER - special, hardened

1шт.

18

95-8

WASHER,1/2"

- lock, 1/2"

2шт.

19

92-8

LOCK WASHER,1/2"

2шт.

20

25-108

NUT,1/2"-13, G5

- hex., 1/2" - 13 N.C.

2шт.

21

13-828

BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5

- hex., 1/2" - 13 N.C. x 1-3/4"

5шт.

22

195-40

WASHER - plain, 1/2"

10шт.

23

L52867

SCREEN - radiator grille

1шт.

24

92-8

LOCK WASHER,1/2"

5шт.

25

25-108

NUT,1/2"-13, G5

- hex., 1/2" - 13 N.C.

5шт.

26

13-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5, Full Thd

2шт.

27

92-8

LOCK WASHER,1/2"

2шт.

28

L51936

COVER - radiator top

1шт.

29

L52700

STRIP - backup, cover

1шт.

30

25-108

NUT,1/2"-13, G5

- hex., 1/2" - 13 N.C.

2шт.

31

13-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd

4шт.

32

95-8

WASHER,1/2"

plain 1/2"

8шт.

33

L52034

PANEL - hood, L.H.

1шт.

34

L52035

PANEL - hood, R.H.

1шт.

35

92-8

LOCK WASHER,1/2"

4шт.

36

25-108

NUT,1/2"-13, G5

- hex., 1/2" - 13 N.C.

4шт.

37

13-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd

Hood top Hex, 1/2"-13 x 1 1/4", G5, Full Thd

6шт.

38

13-816

BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd

Hood top Hex, 1/2"-13 x 1", G5, Full Thd

4шт.

39

92-8

LOCK WASHER,1/2"

10шт.

40

95-8

WASHER,1/2"

plain 1/2"

10шт.

41

L52036

SET OF 2 KEYS

HOOD - top

1шт.

42

L59813

SHIELD

PANEL - side

2шт.

43

L59813

SHIELD

PANEL - side, includes side angles

2шт.
