Запчасти Case 500 (108) - REAR STEERING WHEELS (05) - UPPERSTRUCTURE CHASSIS

1

A13711

WHEEL ASSY. - rear steering

2шт.

2

NSS

NOT SOLD SEPARAT

WHEEL - rear strg. (Order A13711)

1шт.

3

A26678

BEARING CUP,3.6718" OD x 0.9375"

CUP - bearing, inner

1шт.

4

A26680

ROLLER BEARING,2.7510" OD x 0.75"

CUP - bearing, outer

1шт.

5

A27183

NUT

- stud, Serial Range: rim-wheel

10шт.

6

A16726

CLAMP - retainer, wheel rim

10шт.

7

A27454

RIM - wheel (Takes 7.50 x 16 tire)

1шт.

8

A41395

RING - wheel side

1шт.

9

A26011

CAP

- outer brg., wheel

2шт.

10

A27179

STUD

- wheel, rim mtg.

10шт.

11

25-1516

NUT,Jam, 1"-14, G5

- jam, 1" N.F., hex.

4шт.

12

A26542

LOCK WASHER

- lock, spindle nut

2шт.

13

A26681

BEARING WASHER

WASHER - thrust, outer bearing

2шт.

14

A26679

ROLLER BEARING,1.25" ID x 0.9983"

CONE - bearing, outer, wheel

2шт.

15

A27301

ROLLER BEARING,2" ID x 1.193"

CONE - bearing, inner, wheel

2шт.

16

A26993

O-RING,0.21" Thk x 3.725" ID, -343, Cl 5, 75 Duro

"O" RING - wheel seal retainer

2шт.

17

A26992

RETAINER

- seal, rear wheel

2шт.

18

A26991

SEAL

- lube, rear wheel

2шт.

19

75-48

SCREW,Rd, 1/4" - 20 x 1/2"

- mach., 1/4 x 1/2" N.C., rd. hd.

10шт.

20

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

10шт.

25

A13642

WHEEL

- drive (Takes 12.00 x 24 or 13.00 x 24 tire), front, split rim

2шт.

26

A13099

O-RING,22 1" ID x 0.25"

RING - rim, wheel (Rubber), front drive

2шт.

27

A13097

RING

- side, wheel rim, front drive, split

2шт.

28

A13098

RING

- lock, rim side ring, front drive wheels, split rim

2шт.

29

B18264

WHEEL BOLT

BOLT - mtg., drive wheel, front drive wheels, split rim

16шт.

33

A19914

WHEEL

- drive (Takes 12.00 x 24 or 13.00 x 24 tire, solid rim

2шт.

34

A19915

WEIGHT (For A19914 wheel) (510 lbs. ea.) (Mach. item), solid rim

2шт.

35

15-1092

HARDWARE

BOLT - weight, 5/8 x 5-3/4" N.C. hex., solid rim

8шт.

36

92-10

LOCK WASHER,5/8"

WASHER, LOCK, , Solid rim 5/8"

8шт.

37

25-1010

NUT,5/8"-11, G5

Solid rim 5/8"-11, G5

8шт.

38

B18264

WHEEL BOLT

BOLT - mtg., drive wheel, solid rim

16шт.

42

A35906

WHEEL

- drive (Takes 14.9 x 24 tire), solid rim

2шт.

43

G12018

WEIGHT ASSY. (For A35906 wheel) (Set of 2) (Mach. item), solid rim

1шт.

44

11-1052

BOLT (MACHINE)

BOLT - weight, 5/8 x 3-1/4" N.C. carr., solid rim

4шт.

45

92-10

LOCK WASHER,5/8"

WASHER, LOCK, , Solid rim 5/8"

4шт.

46

25-1010

NUT,5/8"-11, G5

Solid rim 5/8"-11, G5

4шт.

47

B18264

WHEEL BOLT

BOLT - mtg., drive wheel, solid rim

16шт.
