Запчасти Case 400 (124) - D45659 PUMP ASSEMBLY, USED ON TRACTOR SERIAL NUMBER 6517 AND AFTER (07) - HYDRAULIC SYSTEM

1

D45659

PUMP - hydraulic, gear type (19 G.P.M. at 2500 R.P.M. at 1800 P.S.I.) When replacing complete pump, order D54170 pump for service, Parts list Figure 125A, Includes; Ref. 2 - 16

1шт.

2

187-1049

SCREW - flat head, self tapping (#10 - 24 NC x 3/8")

3шт.

D46322

PLATE ASSEMBLY - front seal, Includes: Ref. 3 and 4

1шт.

3

NSS

NOT SOLD SEPARAT

PLATE - front seal

1шт.

4

R22149

SEAL

- drive shaft

1шт.

Available as a pump repair kit P/N D52315.

1шт.

5

D46323

O-RING,0.103" Thk x 1.925" ID, -135, Cl 5, 75 Duro

SEAL - O-ring

1шт.

Available as a pump repair kit P/N D52315.

1шт.

6

61-520

HEX SOC SCREW,5/16"-18 x 1 1/4"

BOLT - hex. socket head (5/16" - 18 NC x 1-1/4")

4шт.

7

D46324

WASHER

- special

4шт.

8

61-624

HEX SOC SCREW,3/8"-16 x 1 1/2"

BOLT - hex. socket head (3/8" - 16 NC x 1-1/2")

4шт.

9

A32395

WASHER

- special

4шт.

10

D46326

COVER ASSEMBLY - shaft end

1шт.

11

D46237

PLATE - backup

1шт.

Available as a pump repair kit P/N D52315.

1шт.

12

D46328

LARGE PLATE

PLATE - wear

1шт.

Available as a pump repair kit P/N D52315.

1шт.

D46329

SHAFT AND GEAR SET - drive and driven, Includes: Ref. 13 and 14

1шт.

13

NSS

NOT SOLD SEPARAT

SHAFT AND GEAR - drive

1шт.

14

NSS

NOT SOLD SEPARAT

SHAFT AND GEAR - driven

1шт.

15

D46332

PIN - dowel

2шт.

16

D46333

COVER ASSEMBLY - port end

1шт.
