Артикул
Название
Примечание
Количество
1
A8744
NUT
- acorn (Special)
1шт.
2
92-12
LOCK WASHER,3/4"
WASHER, LOCK, 3/4"
1шт.
3
D45692
WHEEL - steering
1шт.
4
13-624
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
HHCS - 3/8" - 16 NC x 1-1/2"
2шт.
5
92-6
LOCK WASHER,3/8"
2шт.
D45167
PUMP ASSEMBLY - steering, manual, Includes: Ref. 6 - 38
1шт.
6
D46319
OIL SEAL
RETAINER - bearing, outer
1шт.
7
F53335
RING, SNAP
SNAP RING - bearing retaining
2шт.
8
L30881
BALL BEARING,22.4mm ID x 35.8mm OD x 9.6mm W
- steering shaft
1шт.
9
126-119
WOODRUFF KEY,#11, 3/16" x 7/8", HT
KEY - #11 Woodruff
1шт.
10
D46320
SHAFT - steering
1шт.
11
D46321
COLUMN - steering
1шт.
12
166-43
12 PT SCREW,Flg, 3/8" - 16 x 3/4", Gr 8
SCREW - ferry cap (3/8" - 16 NC x 3/4")
2шт.
13
A28211
OIL SEAL
- oil
1шт.
14
166-23
12 PT SCREW,Flg, 5/16" - 18 x 5/8", Gr 8
SCREW - ferry cap (5/16" - 18 NC x 5/8")
4шт.
15
D46317
PLATE ASSY.
COVER - upper
1шт.
16
A72029
RING
SEAL - quad ring
1шт.
17
A72030
SPACER
BUSHING - upper cover
1шт.
18
A17528
O-RING,1.737" ID x 1.943" OD x 0.103"
SEAL - "O" ring
1шт.
D46318
CONTROL
ASSEMBLY - pump, Includes: Ref. 19 - 29
1шт.
19
NSS
NOT SOLD SEPARAT
SPOOL - pump
1шт.
20
L30889
SPRING
- centering
6шт.
21
L30894
PIN
DISC - pin
2шт.
22
L30888
PIN
- centering
1шт.
23
NSS
NOT SOLD SEPARAT
SLEEVE - pump
1шт.
24
L30893
O-RING,1/16" Thk x 5/16" ID
SEAL - "O" ring, 7/16 x 5/16 x 1/16 in
1шт.
25
L30892
PLUG
- seal, housing
1шт.
26
L30891
SEAT
- check
1шт.
27
211-7
BALL,1/4" Dia
- steel 1/4" Dia
1шт.
28
L30890
VALVE SPRING
SPRING - check
1шт.
29
NSS
NOT SOLD SEPARAT
HOUSING - pump
1шт.
30
L30878
DRIVE SHAFT
SHAFT - drive
1шт.
31
D46315
SPACER
- drive shaft, 1/2" long
1шт.
32
C11828
SPACER
- drive shaft, 1" long
1шт.
33
A72026
PLATE
- spacer
1шт.
L30874
GEAR WHEEL
GEAR SET - pump, Includes: Ref. 34 and 35
2шт.
34
NSS
NOT SOLD SEPARAT
STAR - gear
1шт.
35
NSS
NOT SOLD SEPARAT
RING - gear
1шт.
36
D46316
DRIVE SPROCKET
SLEEVE - splined
1шт.
37
A72024
CAP
COVER - lower
1шт.
38
166-537
12 PT SCREW,Flg, 5/16" - 24 x 3 1/2", Gr 8
SCREW - ferry cap (5/16" - 24 NF x 3-1/2")
7шт.
Выбрано товаров: 41
